FEATURES

Standalone Surveillance Solution: Built-in 1080p HDMI output for direct monitor connection
PC-Free Deployment: Easy installation without requiring a computer or internet connection
POS System Integration: Combines transaction records with surveillance footage for enhanced audit tracking
4× Free Camera Licenses Included: Scalable up to 12× IP cameras
Mobile App Support: Monitor live feeds and recordings remotely via Synology mobile app
Energy-Efficient Operation: Power-saving NVR runs below 15W
Expandable Storage: Supports up to 7× HDDs with optional DX517 expansion unit

SPECIFICATIONS

Hardware
Configuration: Supports up to 12× Cameras (4× Camera Licenses Pre-Installed)
CPU: Embedded NVR SoC Dual-Core 1.0GHz
Memory: DDR3 1GB
Compatible Drive Type: 2× 3.5" SATA (Hard Drives Not Included)
External Ports
1× USB3.0, 2× USB2.0, 1× eSATA, 1× HDMI, 2× 3.5mm Audio Jack (Input/Output), 1× COM (For POS System Connection)
Display and Network
Supported Video Output Resolution: 1920×1080 (1080p) @60Hz
LAN: 1× Gigabit (RJ45)
Supported USB Devices: USB Storage, Keyboard, Mouse, Joystick, UPS
Physical
Dimensions (H × W × D): 165 × 100 × 225.5mm
Weight: 0.9kg
Power and Environment
AC Input Power Voltage: 100~240VAC
Power Frequency: 50~60Hz, Single Phase
Power Consumption: 13.64W
Operating Temperature: Adapter: 0~40°C, Chassis: 5~45°C
Storage Temperature: -20~60°C
Relative Humidity: 5~95% RH
Agency Certifications: FCC Class B, CE Class B, BSMI Class B
General Specification
File System: Internal ext4, External ext4, ext3, FAT, NTFS, HFS+ (Read Only)
Supported RAID Type
Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5 (with DX517), RAID 6 (with DX517)
Storage Management
Maximum Single Volume Size: 16TB
Maximum Internal Volume: 256×
Maximum Shared Folder: 256×
Surveillance Station
Maximum IP Camera: 12× Channels (360fps @720p)
Supported Video Codecs
MJPEG, MPEG-4, MxPEG, H.264, H.265 (MxPEG and H.265 Do Not Support Local Display)
Recording Modes
Manual, Continuous, Motion Detection, I/O Alarm, Action Rule, Customised
Playback
Timeline Playback, Frame-by-Frame, Digital Zoom, Embedded Watermark for Evidence Integrity
Camera Support
ONVIF 2.6 (Profile-S Certified, Profile-G for Edge Recording)
PTZ Support
Adjustable Bit-Rate (Constant and Variable)
