TMAEW3000
TMAEW3000 Features & Specifications:
Rated Line Pull | 3000Lb (1361Kg) Single Line |
Motor | 12 V DC 1.1hp, Permanent Magnet |
Control | Remote Control Included |
Gear Ratio | 153:1 |
Clutch | Turn 90° by Handwheel |
Braking | No |
Drum Size | Diameter x Length 1.61" x 2.9" (41mm x 74mm) |
Wire Cable | Diameter x Length 1/5" x 50' (5.1mm x 15.2m) |
Recommended Battery | 12Amp/Hour Minimum |
Weight | 29Lb (12kg) |
Overall Dimensions | (LxWxH) 12.35" x 7.40" x 4.72" (313 x 188 x 120mm) |
Mounting Bolt Pattern | 367" (93mm) |
Fairlead | Roller Fairlead |
TMAEW3000 Line Pull &Cable Capacity
Layer of Cable |
| 1 | 2 | 3 | 4 | 5 | 6 |
Rated Line | Lbs | 3000 | 2400 | 2000 | 1714 | 1500 | 1330 |
Pull per Layer | Kg | 1361 | 1090 | 907 | 778 | 680 | 600 |
Cumulative | Ft | 5.9 | 13.7 | 22.6 | 32.8 | 44.2 | 50.0 |
Cable Capacity | m | 1.8 | 4.7 | 6.9 | 10.0 | 13.5 | 15.2 |
