Specifications:
Main Controllers:
MCU1: RP2040 32-bit dual ARM Cortex-M0+; Flash 16MB; SRAM 264KB
MCU2: ESP32-C6 32-bit RISC-V low-power WiFi 6 SOC; Flash 4MB; SRAM 512KB
Connectivity: 2.4 GHz Wi-Fi 6, Bluetooth 5 (LE), IEEE 802.15.4 protocol
Display: 2.33-inch touch IPS TFT LCD; Resolution: 222 (H) RGB x 480 (V); Display Driver: ST7796; Interface: SPI
Sensors: I2C Digital Light Sensor LTR-553ALS-01 with ALS and proximity [PS] capabilities
Storage: Supports SD card expansion
Battery: Onboard 3.8V 470mAh @ 0.2C rechargeable
Input/Output: Capacitive touch display, TF Card slot, boot and run buttons, USB plug modes
Features:
1. Dual-Controller Design
Boasts RP2040 ARM Cortex-M0+ and ESP32-C6 RISC-V SOC for efficient multitasking and reliable performance in complex projects.
2. Enhanced Display Capabilities
Equipped with a 2.33-inch IPS TFT LCD with high-resolution 222 x 480 pixels, delivering vivid visuals and an intuitive touch interface.
3. Advanced Connectivity
Supports the latest wireless protocols: Wi-Fi 6 for high-speed data transfer, and Bluetooth 5 (LE) along with IEEE 802.15.4 for secure, low-power communication.
4. Expansion and Customization Options
Includes SD card support and multiple GPIO pins for increased flexibility in development projects.
5. Integrated Light Sensor
Built-in light and proximity sensor (LTR-553ALS-01) enhances interactive applications and environmental adaptability.
Package Included:
1 x T-Pico-Pro C6 Module
2 x 2.54 mm Pin (13 pins)
