Specifications:
Processor: ESP32-WROVER-E MCU with integrated Wi-Fi and BLE v4.2 capabilities.
Memory: 16MB Flash and 8MB PSRAM for data processing.
Ethernet: LAN8720 Ethernet network port supporting 10BASE-T/100BASE-TX connections with low power consumption.
Power Supply: POE module compliant with IEEE802.3af/at, input voltage range 44V~57V, and output 5V@4A.
Interface: USB Type-C, RS485, TF card support, and multiple GPIO pinouts and connections for flexibility.
Dimensions: Compact design with L × W × H: 10.4 cm × 8.6 cm × 1.8 cm for T-POE Pro; L × W × H: 72 mm × 52 mm × 17 mm for T-Internet-POE V2.
Features:
1. Fully supports IEEE802.3af/at PoE standards for reliable power delivery over Ethernet.
2. Flexible power management architecture for high efficiency in operations.
3. Onboard reset and boot buttons to facilitate user interaction.
4. Expandable functionalities, including LCD screen and additional modules.
5. Integrated CH340C serial chip for seamless communication and programming.
6. Compatible with T-U2T auto-downloader for program uploads.
Package Includes:
1 x T-Internet-POE Board with pins
or
1 x T-POE-Pro Board with pins
or
1 x T-Internet-POE V2 Board
1 x Downloader
or
1 x Downloader
