2K 5MP Live View: Always know what happens in front of your door through the Tapo app. With the starlight sensor and 2K 5MP resolution, check all the fine details captured even in low-light environments.
Color Night Vision: With the embedded spotlight and starlight sensor, Tapo D230S1 reveals high-fidelity details and color at night.
Head-to-Toe View: With the camera's ultra-wide FOV(160 Diagonal), Tapo 4:3 live view ensures users can check visitors from head-to-toe as close as 1m , which shows more vertical details than other 16:9 doorbells'.
Flexible Placement, Flexible Views: Different wedge choices allow users to make the doorbell suits more placement scenarios. Users can also use wedges to adjust the views.
Longer Battery Life: The rechargeable and removable battery with a low-power protocol extends your usage.
Smart AI Detection and Notification: Smart AI algorithms identify people and cars, and notify users as needed.
Multiple Ways to Answer: With two-way audio or a recorded quick response, communicate directly with your deliveries through the Tapo app.
Flexible Storage Choice: Save recorded videos on the hub-installed microSD card (up to 512 GB) or by using Tapo Care cloud storage services.
Anti-theft Alarm: Be alerted when someone trying to take the doorbell off with the anti-theft alarm function.
Water & Dust Resistant IP64: Operates well on rainy days and in damp environments.
Specifications:
CAMERA
- Image Sensor: 1/3" Progressive Scan CMOS
- Lens: 2.1mm 5%
- Field of View (FOV): 150 (Diagonal)
- Night Vision: 850 nm IR LED (up to 98 ft), Color Night Vision with Starlight Sensor
- Lighting: 4× Built-in Spotlights
- Interface & Button: 1× RESET Button, 1× POWER Button
- Resolution: 2K QHD 4MP (2560 × 1440 px)
VIDEO AND AUDIO
- Live View: Supports
- Frame Rate: 30fps
- Video Streaming: 2560 x 1440
- Video Compression: H.264
- Audio Input & Output: Built-in Microphone and Speaker, Two-Way Audio with Noise Cancellation
VIDEO & AUDIO
- Maximum Resolution: 2K QHD 4MP (2560 × 1440 px)
- Frame Rate: 15/20/(25/30)fps
- Digital Zoom: 12×
- Video Compression: H.264
- Live View: Yes
- Image Enhancement: 3DNR, WDR
- Audio Input & Output: Built-in Microphone and Speaker, Two-Way Audio with Noise Cancellation
- Siren Volume: 94 dB (Level measured at 4-inch/10-cm distance)
STORAGE
- Local Storage: Supports microSD Card (Up to 512GB) (Purchase Separately)
- Cloud Storage: Supports Cloud Storage (Subscription required)
DETECTION AND NOTIFICATIONS
- Sensor: Single Motion Sensor (FOV: 130 horizontal), Single Ambient Light Sensors
- AI Detection: Motion Detection, Person Detection, Pet Detection, Vehicle Detection
- Activity Zones: Yes
- Output Notification: System Notification, System Notification with Snapshot (Tapo Care Services)
NETWORK
- Network Connectivity: Connect via Wi-Fi
- Wireless Connectivity: IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
- Protocol: TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
- Wireless Standard: 802.11 b/g/n wifi connection @ 2.4G
- Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 72.2Mbps
- Wired or Wireless: Wireless
SECURITY
- Security: 128-bit AES Encryption with SSL/TLS, WPA/WPA2-PSK
- Network Security: SSL/TLS, AES
- Wireless Security: WPA/WPA2-PSK
POWER
- Power Source: 10000 mAh Built-in Rechargeable Lithium-ion Battery, Optional Solar Panel: Tapo A200 (Sold separately)
- Input Voltage: Adapter Input: 100-240 V, 50/60 Hz
- Output Voltage: Adapter Output: 5.0 V, 2.0 A
- AC adapter input: 100-240V, 50/60Hz
- AC adapter output: 5.0V, 2.0A
GENERAL
- Smart Integration: Google Assistant, Amazon Alexa
- Weather Resistance: IP66
- System Requirements: Tapo App: iOS 11.0 or higher, Android 5.0 or higher
- Mounting Options: Tabletop, Ceiling-Mounted, Wall-Mounted
- Operating Temperature: Camera: -20 C ~ 45 C (-4 F ~ 113 F), Hub: 0 ~40 (32 F ~ 104 F)
- Storage Temperature: -20 ~60 (-4 F ~ 140 F)
- Operating Humidity: 10%~90% RH, Non-condensing
- Storage Humidity: 5%~90% RH, Non-condensing
- Charging Temperature: 0-45
- Dimensions: Camera Dimensions: 4.57 × 2.55 × 2.55 in (116.2 × 64.8 × 64.8mm)
- Weight: 235g
- Mounting Methods: Magnetic suction mounted on iron surface; Ceiling-Mounted or Wall-Mounted via Screws
- Certifications: CE, FCC, RoHS, RCM
ACTIVITY NOTIFICATIONS
- Detection Category: Motion detection, Person detection, Pet detection, Vehicle detection
- Activity Zones: Supports
- Output Notification: notification, snapshot (Tapo care), clips (Tapo care).
HARDWARE
- Button: Reset/Power Button
- Indicator LED: System LED
- Spotlight: 2 Built-in Spotlights
COMPATIBILITY
- APP Supports: Tapo APP
- Third-Party Platform: Google Assistant, Amazon Alexa
What's in the box
Tapo Video Doorbell × 1
Tapo H200 Hub × 1
Tapo A100 Battery × 1
DC Power Adapter × 1
USB Adapter × 1
USB Adapter Cable × 1
RJ45 Ethernet Cable × 1
Inclined Mounting Templates × 1
Mounting Templates × 2
Mounting Brackets × 1
15 Mounting Wedge × 1
Doorbell Detaching Pin × 1
Screws and Anchors × 2
Quick Start Guide
