Targa TG-D20BR Bass Race Series Xtreme SPL Competition 9500rms Class D Monoblock Amplifier
The Targa TG-D20BR Bass Race amplifier is a high-output Class D monoblock designed for demanding car-audio installations. Its advanced full-bridge design and high-efficiency IR Class D technology deliver substantial power from a compact chassis.
An intelligent MCU power-management and protection system helps maintain reliable operation, while the supplied long-range wired remote allows convenient control from the front of the vehicle. The TG-D20BR also supports remote monitoring of its operating status through an LED display.
FEATURES
High-efficiency IR Class D technology
Advanced full-bridge amplifier design
MCU-controlled power management and protection
High power output from a compact enclosure
Long-range wired remote control
Remote LED operating-status display
Heavy-duty 0-gauge power and ground terminals
SPECIFICATIONS
Model: TG-D20BR
Series: Bass Race
Amplifier type: Class D monoblock
RMS power at 4 ohms: 1 × 2,800 W
RMS power at 2 ohms: 1 × 5,200 W
RMS power at 1 ohm: 1 × 9,500 W
Minimum working impedance: 1 ohm stable
Input sensitivity: 0.25 V
High-pass filter: 1090 Hz
Low-pass filter: 90 Hz17 kHz
Bass boost: 012 dB
Frequency response: 10 Hz17 kHz
Signal-to-noise ratio: Greater than 84 dB
Total harmonic distortion: Less than 1%
Operating voltage: 916 V
Dimensions: 11.81 × 9.01 × 2.46 inches
