Features

• Auto-chromatic pitch correction improves your pitch
• Adjustable auto-smooth compression
• Multi-band auto-shape EQ dynamically sweetens raw mic sound
• Sibilance-smoothing de-ess algorithm
• Add rich lows on deep voices with the Warmth button
• Accurate input pitch and correction display
• XLR mic level I/O: Correction can go to monitors, mains or both
• Clean, studio quality mic preamp with phantom power

• Analog Inputs
• Connectors: Balanced XLR
• Input Impedance: 1 kOhm
• Mic Input Sensitivity @ 0 dBFS: -44 dBu to +2 dBu
• Mic Input Sensitivity @ 12 dB headroom: -56 dBu to -10 dBu
• EIN: -128 dBu @ max. mic amp gain, Rg = 150 Ohm
•
• Analog Outputs
• Connectors: Balanced XLR
• Output Impedance: 40 Ohm
• Output Level @ 0dBFS: +2dBu
•
• Input to Output Analog Audio Performance
• Dynamic Range, Mic. @ Min gain: >108 dB, 20 Hz - 20 kHz (A-weighted)
• Dynamic Range, Mic. @ -18dBu sensitivity: > 104dB, 20hz — 20kHz (A-weighted)
• THD+ Noise, Mic. @ Min gain: <-90dB
• Frequency Response, max gain: -1.5 dB @ 40 Hz, +0/-0.3 dB (200 Hz to 20 kHz)
•
• Conversion Characteristics
• Sample Rate: 48 kHz
• Converter: AKM AK4620B
• A to D / D to A Conversion: 24 bit, 128x oversampling bitstream
• A to D D: 0.65 ms
• D to A D: 0.63 ms
• EMC
• Complies with: EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
•
• Safety
• Certified to: IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE #LR108093
•
• Environment
• Operating Temperature: 32° F to 122° F (0° C to 50° C)
• Storage Temperature: -22° F to 167° F (-30° C to 70° C)
• Humidity: Max. 90% non-condensing
•
• Supplementary
• Dimensions: 130mm x 132mm x 41mm (5" x 5.25" x 1.5")
• Weight: 1.5 lb. (0.72 kg)
• Warranty Parts and labor: 1 year
