TDK (CLF7045NIT-2R2N-D) Power Inductor (SMD), 2.2 µH, 5.1 A

Power Inductor (SMD), 2.2 µH, 5.1 A, Shielded, 6.2 A, CLF-NI-D, 7.4mm x 7mm x4.5mmProduct InformationInductance: 2.2µHRMS Current (Irms): 5.1AInductor Construction: ShieldedSaturation Current (Isat): 6.2AProduct Range: CLF-NI-DPower Inductor Case: 7.4mm x 7mm x 4.5mmDC Resistance Max: 0.013ohmInductance Tolerance: ± 30%Product OverviewThe CLF-NI-D series from TDK are automotive grade wire wound inductors for powercircuits.Automotive grade AEC-Q200 qualifiedInductance value range from 1µH to 470µH, wide E-6 Series line-up allows forvarious usagesTolerance range from ±30% and ±20%100KHz measuring frequencyDC resistance range from 0.009ohm to 1.2ohmRated current Isat range from 0.41A to 8.5A and Itemp range from 0.46A to 6.5AMagnetic shield type wound inductor for power circuits, ferrite coreOperating temperature range from -55°C to +150°CDimension is 7.4mm x 7mm x 4.5mm (L x W x T)
