TDK (SPM4020T-4R7M-LR) Power Inductor (SMD), Wirewound, 4.7 µH, 2.5 A

TDK (SPM4020T-4R7M-LR) Power Inductor (SMD), Wirewound, 4.7 µH, 2.5 A

New 496 available
R149.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 7 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
2564035RL
Bob Shop ID
647349250
Power Inductor (SMD), Wirewound, 4.7 µH, 2.5 A, Shielded, 3.5 A, SPM-LR, 4.4mm x4.1mm x 2mmProduct InformationInductance: 4.7µHRMS Current (Irms): 2.5AInductor Construction: ShieldedSelf Resonant Frequency Min: -Saturation Current (Isat): 3.5ADC Current Rating: 2.5AProduct Range: SPM-LRPower Inductor Case: 4.4mm x 4.1mm x 2mmInductor Case Style: 4.4mm x 4.1mm x 2mmDC Resistance Max: 0.1472ohmInductance Tolerance: ± 20%Core Material:Product OverviewThe SPM-LR series 4020 type from TDK are commercial grade magnetic shield typewire wound inductors for power circuits using a metallic magnetic material.Inductance value range from 0.47µH to 10µHLow profile productMaximum DCR value range from 11.8mohm to 284.1mohm, Isat current range from 2.3Ato 14.1ALow inductance variance in high temperature environments with good DCsuperimposition characteristicInductive tolerance of ±20%Operating temperature range from -40°C to +125°CCompared to ferrite wound type inductors, possible to achieve large current, lowRdc and compactnessDimensions is 4.4mm x 4.1mm x 2mm (L x W x H)Reflow iron soldering method
