TDK (VLS6045EX-150M) Power Inductor (SMD), Wirewound, 15 µH, 2.5 A

Power Inductor (SMD), Wirewound, 15 µH, 2.5 A, Shielded, 3.1 A, VLS-EX, 6mm x6mm x 4.5mmProduct InformationInductance: 15µHRMS Current (Irms): 2.5AInductor Construction: ShieldedSelf Resonant Frequency Min: -Saturation Current (Isat): 3.1ADC Current Rating: 2.5AProduct Range: VLS-EXPower Inductor Case: 6mm x 6mm x 4.5mmInductor Case Style: 6mm x 6mm x 4.5mmDC Resistance Max: 0.075ohmInductance Tolerance: ± 20%Core Material: FerriteProduct OverviewThe VLS6045EX series from TDK are high magnetic shield type inductors. Theseinductors are manufactured with ferrite magnetic material which is typicallyused in power circuits.Dimension of 6mm (L) x 6mm (W) x 4.5mm (H)Inductance value range from 0.47µH to 220µHRated current available in two range of values 800mA to 13.5A (Idc1) and 500mAto 7A (Idc2)DCR value range from 0.010 ohm to 1.15ohmAvailable in ±20%, ±30% tolerance valuesOperating temperature of -40°C to 105°CCompatible with high density mountingLarger current and lower Rdc have been achieved by optimizing the ferrite corefigure0.6g of weight
