TE Connectivity (3-640441-9) IDC Connector, 24 AWG, IDC Receptacle, Female

IDC Connector, 24 AWG, IDC Receptacle, Female, 2.54 mm, 1 Row, 9 Contacts, CableMountProduct OverviewThe MTA-100 series MTA Connector System is a wire-to-board and wire-to-wiresystem based on insulation displacement contact (IDC) technology. Masstermination of wires provides the lowest applied cost because it drasticallyreduces the labour content of virtually any cable or harness assembly required.MTA 100 connectors have contacts in a single row on 0.100-inch (2.54mm) centre.The design features wire feed-through capability for daisy-chain applications.Insulation displacement contacts (IDC) are used to terminate a wide range ofconductor sizes. Ribbon cable can also be terminated when the appropriatereceptacle assembly and strain relief cover are used. Header assemblies forboard mount applications include right-angle and vertical mount productsavailable in through-hole and surface mount configurations.Colour coded housing for wire gageTin, 15 and 30 gold plating optionsAudible latch for wire-to-wire (posted) housingsTerminates 28 to 22AWG discrete wire or notched ribbon cable2 to 28 Positions ad shrouded headers 2 to 14 available250V and 5A RatingApplicationsIndustrialProduct InformationIDC Connector Type: IDC ReceptacleContact Gender: FemalePitch Spacing: 2.54mmNo. of Rows: 1 RowNo. of Contacts: 9ContactsConnector Mounting: Cable MountContact Material: Copper AlloyContact Plating: Tin Plated ContactsProduct Range: MTA-100 Series
