TE Connectivity (7-215570-6) IDC Connector, Board In Connector, 1.27 mm

IDC Connector, Board In Connector, 1.27 mm, 2 Row, 6 Contacts, Cable Mount,Through Hole MountProduct OverviewThe 7-215570-6 is a 6-position vertical Wire-to-Board Pin Header with tin overnickel-plated phosphor bronze contacts and red GF polyester housing. TheMicro-MaTch series connector supports through-hole termination method to PCboard?and Insulation Displacement Crimp (IDC) termination method to wire/cable.The Micro-MaTch connector family, with its contact spacing of 1.27mm, offers avariety of wire-to-board interconnections. The Micro-MaTch contact helps preventfretting corrosion, the traditional failure mode in tin-plated connections.Relative movements caused by vibrations/thermal expansion between male andfemale contacts are absorbed by an additional positioning spring in the femalepart. By preventing movements on the contact spot, a gas tight connection canmake the Micro-MaTch contact spring system fretting corrosion resistant.Kink PCB mount retentionPolarization mating alignmentApplicationsAudio, WirelessProduct InformationPitch Spacing: 1.27mmIDC Connector Type: Board In ConnectorNo. of Contacts: 6ContactsNo. of Rows: 2 RowConnector Mounting: Cable Mount, Through Hole MountContact Material: Phosphor BronzeContact Plating: Tin Plated ContactsProduct Range: Micro-MaTch
