9-30 VDC Passive PSU/POE Input, DIN rail or wall mountable, NO POE OUT
Performance Specifications: Bandwidth (Non-blocking): 10 GbpsPacket buffer: 128 KBJumbo frame support: 9216 bytesMAC address table size: 2K entriesConnector: 4 pin industrial DC power socketInput voltage range: 9 - 30 VDC, reverse polarity protection, voltage surge/transient protectionPoE (passive): Passive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standardsPower consumption (idle/max): < 0.4 W/ <1.8 W
Datasheet Download
