| Weight | 780 g |
|---|
| Dimensions | 300 × 425 × 405 mm |
|---|
| Video | IP Video Input: 8-ch
IP Video Resolution: Up to 8MP
Input Bandwidth: 60 Mbps
Audio Input: 1-ch, RCA (2.0 Vp-p, 10k) |
|---|
| Video & Audio Output | HDMI Output: 1-ch, 4K(3840×2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
Output Bandwidth: 60 Mbps
Audio Output: 1-ch, RCA (2.0 Vp-p, 10k) |
|---|
| Video & Audio Decoding | Video Decoding Format: H.265+, H.265, H.264+, H.264
Audio Decoding Format: G.711A, G.711U, G726
Recording Resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
Decoding Capability: 4-ch@1080P(30 fps)
Stream Type: Video, Video & Audio |
|---|
| Recording Management | Record Mode: Normal, Alarm
Playback Mode: Instant, Channel, File, Tag
Sync Playback: Up to 8-ch
Backup Mode: USB device |
|---|
| Network Managemant | Ethernet Port: 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
Network Protocol: HTTP, HTTPS, WebSockets, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, DDNS
Mobile Client: Supports iOS, Android
Web Browser: Plug-in free live view : Chrome, Edge, Opera |
|---|
| PoE | PoE Port: 8 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet ports
PoE Standard: IEEE 802.3at/802.3af
PoE Power: 70 W |
|---|
| HDD Storage | HDD Interface: 1 SATA 3.0 interface
Capacity: Up to 10 TB capacity for each HDD |
|---|
| External Interface | USB Port: 2 x USB 2.0 |
|---|
| General | Power: 48 VDC, 1.875 A
Dimension: 284 mm × 207 mm × 43 mm (11.2 " × 8.2 "× 1.7 ")
Weight (Without HDD): 780 g (1.72lb)
Certification: CCC, CE, FCC, RoHS
Installation Method: Desktop mounting, wall mounting Temperature:
Operating Temperature: 0°C 40°C (32°F 104°F)
Storage Temperature: -30°C 70°C (-22°F 158°F) Humidity:
Operating Humidity: 10% 90% RH (non-condensing)
Storage Humidity: 5% 95% RH (non-condensing) |
|---|
