Brand New & Sealed with Manufacturer Warranty
16 x 10/100/1000 Mbps auto-negotiation RJ45 ports, up to 2000 Mbps of full duplex transmission rate, line-speed forwarding by all ports, and large cache capacity ensure the timely transfer of large files and stable streaming video. Stay connected for 7/24.
Professional integrated lightning protection circuit enables all the 16 ports to provide IV-class (6 kV in common mode) lightning protection, effectively decreasing the damage rate to the ports by lightning surge.
The 16-gigabit ports enable you to experience lower latency and faster transfer speed, ensure instant transfer of large files and stable video streams and improve network usage experience in various scenarios.
| Specification | Details |
|---|---|
| Model | TEG1016G |
| Product Type | 16-Port Gigabit Ethernet Switch |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab |
| LED Indicator | Power, Link/Act |
| Interfaces | 16 x 1GE RJ45 ports |
| Transmission Media | Recommended: CAT5/5e UTP or better |
| Dimensions | 440 x 120 x 44 mm |
| Material | Metal |
| Level of Protection | Port: 6 kV; Power: 4 kV |
| Forwarding Mode | Store-and-forward |
| Switch Capacity | 32 Gbps |
| Forwarding Rate | 23.80 Mpps |
| Buffer | 4 Mb |
| MAC Address Table | 8K |
| Power Method | 100-240V AC, 50/60Hz |
| Power Consumption | Max: <12W |
| Mounting | Rack mounting, desktop mounting, wall mounting |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
| Certifications | FCC, CE, RoHS |
