Active Light and Sound Alarms for Enhanced Defense
When intrusion is detected during the alert period, a sound and white flashing light alarm will be triggered to warn illegal intruders. At the same time, the alarm message will be sent to your mobile. You can set the pan/tilt patrol locations
via the TDSEE App, and the camera rotates cyclically according to the preset location to patrol the area.
Auto Targeting and Tracking
Based on the AI machine vision algorithms, the "Smart Tracking" can automatically track the movements and store the video.
Active Light and Sound Alarms for Enhanced Defense
When intrusion is detected during the alert period, a sound and white flashing light alarm will be triggered to warn illegal intruders. At the same time, the alarm message will be sent to your mobile.
Two-Way Audio Easy Communication Anytime & Anywhere
Real-time full-duplex two-way audio communication function enables you to chat with your family anytime and anywhere, bringing the most affectionate greetings to your beloved.
Customize your voice alerts
You can customize 3 personalized audio messages for a shop greeting or a theft warning
Tenda, the Wireless Transmission Expert
The built-in dedicated antennas increase Wi-Fi performance by 30% and video is still smooth after passing through 2 walls.
Three Storage Options
The video can be stored in local Micro SD card, cloud storage and NVR storage. Even a vandal accident happens to your devices, you can still retrieve videos based on cloud recording.
Support Desktop, Ceiling and Wall Mounting
The product is delivered with a separated "Base". The camera can be directly placed on the desktop, or the top of the wardrobe, etc. You can also install the "Base" on the ceiling or wall first, then buckle the "Camera" on the "Base" and by rotating it about 40°. The screen rotation function in APP is necessary when you install CP3 on the ceiling.
Technical Specifications
| Dimensions | 525 × 450 × 215 mm |
|---|
| Camera | Image Sensor: 1/3 Progressive Scan CMOS sensor
Day and Night: ICR type
Bracket Angle Adjustment |
|---|
| Lens | Focal Length: 4mm
Aperture: F2.2
FOV: Horizontal : 79.4°, Vertical : 48°, Diagonal : 87° |
|---|
| Illuminator | Supplementary Light: 4 IR Lights
Supplementary Light Distance: Up to 10 m/32 ft (depending on environment)
IR Wavelength: 850nm
Night Vision Mode: Black & White Mode |
|---|
| Video | Video Encoding Format: H.264
Main Stream Resolution: 1920 × 1080, 1280 × 720
Sub Stream Resolution: 640 x 360
Frame Rate: 1-15fps,Default 15fps
Bit Rate: 256kbps 8192kbps
Bit Rate Control: VBR |
|---|
| Audio | Audio Encoding Format: G.711A
Audio Sampling Rate: 8 kHz
Audio Communication: Two-way Audio |
|---|
| Image | Image Enhancement: DWDR, 3D DNR
Privacy Mask |
|---|
| Network | Ethernet Port
ONVIF: Support
Protocols: TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP
Web Browser |
|---|
