Thermoelectric Cooler Peltier Plate and Insulation Pad **IN STOCK**
Sold

Thermoelectric Cooler Peltier Plate and Insulation Pad **IN STOCK**

4 were available / new
R68.00
Shipping
R65.00 Standard shipping applies to orders under R100.00, in most areas in South Africa. R35.00 Standard shipping applies to orders over R100.00. Some areas may attract a surcharge surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller allows collection for this item. Buyers will receive the collection address and time once the order is ready.
The seller has indicated that they will usually have this item ready to ship within 2 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
HEA300/HEA302
Bob Shop ID
343058134

Thermoelectric Cooler Peltier Plate 12706 & Insulation Pad:

* This device must be used in conjunction with a heatsink to avoid overheating!

Description:

They consist primarily of semiconductor material sandwiched between ceramic plates and have no moving parts. Each device is fully inspected and tested. Fitted with 6-inch insulated leads.

Specifications:

Chip Type: TEC1-12706
External Dimensions: 40 * 40 * 3.75mm
Internal Resistance: 2.1 ~ 2.4Ω (ambient temperature of 23 ± 1 'C, 1kHZ Ac test)
The Maximum Temperature Difference: Tmax (Qc = 0) above 59 'C.
Working Current: Imax = 4.3-4.6A (rated at 12V)
Rated Voltage: 12V (Vmax: 15V starting current 5.8A)
Cooling Power: Qcmax 55W
Working Environment: Temperature range -55 'C ~ 83'C (high ambient temperature drop directly affect the cooling efficiency)



Uses:

Within seconds one side becomes ice cold the other becomes boiling hot. Used for numerous applications from CPU coolers to alternate power sources, or even for your own custom car drink warmer/cooler.
