TL-Smoother Plus - Stepper Filter Module

3D Printing is one of the most exciting hobbies for people who love tomakethings, as it’s a beautiful culmination of almost all of the differentfieldsof engineering, from electrical to mechanical and even chemicalengineering aswell. And despite how complex most 3D Printers seem to be froman outsideperspective, once you go into the inner workings it gets a lotmorecomplicated, with these TL-Smoother Plus Stepper Filter Modules beinganexcellent example of just how complex it can get.

These simple but very cleverly-designed modules are built with flybackor“freewheeling” diodes, in order to filter out induction voltages andfeedbackso as to smoothen the electrical signal waves for smootheracceleration,movement and stopping times. In 3D Printing, this can make a bigdifference inthe quality of prints produced, as it ensures the Stepper Driversand motorsalways deliver the exact electrical signals, and in turn mechanicalmovements,that you’re expecting – resulting in prints that look and feel greatwithoutany signs of motor jerking or the common “Salmon Skin” problem.

TL-Smoother Plus: Stepper Filter Module - Technical Specifications:

• Number of Flyback Diodes

|

– 8

• Included Cable

|

– 4-Pin Female to 4-Pin Female

• Mounting Points

|

– Ø2.3mm Hole on Each Corner

• Diode: Model Number

|

– S3M: Surface Mount Flyback Diode

• Diode: DC Blocking Voltage (V R)

|

– 1000V

• Diode: RMS Reverse Voltage (V RMS)

|

– 700V

• Diode: Average Rectified Output Current

|

– 3A @ TT = +75°C

• Module Dimensions

|

– Approx. 50 x 25mm

Typical Applications for TL-Smoother Plus - Stepper Filter Module:

These TL-Smoother Stepper Filter Modules are designed and builtspecificallyfor 3D printing, and have been stocked to help you improve thequality of yourprints by ensuring that all the electrical signals arecoherent, evenly spreadand consistent throughout each wave cycle. They fitbetween the stepperdrivers and the Stepper Motors, where they help reducefeedback and inductivecharges with flyback diodes.
