Features:

1. Trace telephone wire/LAN cable

2. Trace wire in electrical system

3. Verify LAN cable condition

4. Continuity test

5. Low Battery Indication

6. Bright white LED flash light

7. Cable Assignment Test:

• Open, short and cross of LAN cable,
• 2-wire (RJ11)
• 4-wire (RJ45) Telephone cable

8. Cable State Testing (2-wire)

a. Line DC detecting and anode, cathode determination

b. Ringing signal detecting

c. Open, short and cross test

 Specification:

Power supply: DC 9V battery

Working current: Tester: ≤20mA;  Receiver: ≤150mA

Signal transfer mode: Digital signal

Signal output level: 8Vp-p

Signal transfer distance: ≥3Km

Dimension: Transmitter: 130x60x33mm;  Receiver:210x35x25mm

Packaging Details

Package Weight: 0.22kg

Package Size: 21.5cm x 13.5cm x 8cm
