The Toshiba 12TB MG Series 3.5 Inch Enterprise SATA Hard Drive features an innovative 9-disk helium-sealed design, offering superior storage density and performance at 7,200 RPM. With a SATA 6.0 Gbit/s interface and a low operational power profile, it provides excellent power efficiency and a workload rating of 550 TB transferred per year. Ideal for enterprise applications, this hard drive ensures reliable data management with options for Sanitize Instant Erase (SIE) for enhanced security.
Specifications
Product code: HDEPW11GEA51
Description: Toshiba 12TB MG Series 3.5 inch Enterprise SATA Hard Drive
Sector Size 512 emulation (512e)
Form Factor 3.5-Inch
Interface SATA-3.3
Formatted Capacity 12TB / 12,000GB
Performance Interface Speed
6.0 Gbit/s
3.0 Gbit/s
1.5 Gbit/s
Rotation Speed 7,200 RPM
Buffer Size 256 MiB
Maximum Sustained Data Transfer Speed (Typ)
242 MiB/s
Logical Data Block Lenth MG07ACAxxxE/EY
Host:512 GB, Disk:4,096 GB
Supply Voltage Allowable Voltage
12 V ± 10% / 5 V + 10% / -7%
Power Consumption Random Write / Read 4KB Q1 (Typ)
7.83 W Typ
Active Idle (Idle-A)
4.25 W Typ.
Acoustics Active Idle (Typ)
20 dB Typ
Ambient Temperature Operating
5°C to 55°C
Non-Operating
-40°C to 70°C
Relative Humidity operating
5% to 90% R.H. (No condensation)
5% to 95% R.H. (No condensation)
Altitude Operating
-305 m to 3,048 m
Non-Operating
-305 m to 12,192 m
Shock Operating
686 m/s {70 G}(2 ms duration)
Non-Operating
2,450 m/s {250 G} (2 ms duration)
Vibration Operating
7.35 m/s {0.75 G} (5 to 300 Hz
2.45 m/s {0.25 G} (300 to 500 Hz)
Non-Operating
29.4 m/s {3.0 G} (5 to 500 Hz)
MTTF 2,500,000 hours
Non-recoverable Error Rate 10 error per 1016 bits read
Load / Unload 600,000 times
Length (Max) 147.0 mm
Weight (Max(Typ)) 720 g / 1.59 lbs
48Months Warranty carry-in
