The Toshiba 12TB MG Series 3.5 Inch Enterprise SATA Hard Drive features an innovative 9-disk helium-sealed design, offering superior storage density and performance at 7,200 RPM. With a SATA 6.0 Gbit/s interface and a low operational power profile, it provides excellent power efficiency and a workload rating of 550 TB transferred per year. Ideal for enterprise applications, this hard drive ensures reliable data management with options for Sanitize Instant Erase (SIE) for enhanced security.
Specifications
-Product code: HDEPW11GEA51
-Description: Toshiba 12TB MG Series 3.5 inch Enterprise SATA Hard Drive
-Sector Size 512 emulation (512e)
-Form Factor 3.5-Inch
-Interface SATA-3.3
-Formatted Capacity 12TB / 12,000GB
-Performance Interface Speed
-6.0 Gbit/s
-3.0 Gbit/s
-1.5 Gbit/s
-Rotation Speed 7,200 RPM
-Buffer Size 256 MiB
-Maximum Sustained Data Transfer Speed (Typ)
-242 MiB/s
-Logical Data Block Lenth MG07ACAxxxE/EY
-Host:512 GB, Disk:4,096 GB
-Supply Voltage Allowable Voltage
-12 V plus or minus 10% / 5 V + 10% / -7%
-Power Consumption Random Write / Read 4KB Q1 (Typ)
-7.83 W Typ
-Active Idle (Idle-A)
-4.25 W Typ.
-Acoustics Active Idle (Typ)
-20 dB Typ
-Ambient Temperature Operating
-5 deg C to 55 deg C
-Non-Operating
--40 deg C to 70 deg C
-Relative Humidity operating
-5% to 90% R.H. (No condensation)
-5% to 95% R.H. (No condensation)
-Altitude Operating
--305 m to 3,048 m
-Non-Operating
--305 m to 12,192 m
-Shock Operating
-686 m/s {70 G}(2 ms duration)
-Non-Operating
-2,450 m/s {250 G} (2 ms duration)
-Vibration Operating
-7.35 m/s {0.75 G} (5 to 300 Hz
-2.45 m/s {0.25 G} (300 to 500 Hz)
-Non-Operating
-29.4 m/s {3.0 G} (5 to 500 Hz)
-MTTF 2,500,000 hours
-Non-recoverable Error Rate 10 error per 1016 bits read
-Load / Unload 600,000 times
-Length (Max) 147.0 mm
-Weight (Max(Typ)) 720 g / 1.59 lbs
-48Months Warranty carry-in
