Hardware Features
- Interface: 4 10/100Mbps LAN ports, 1 10/100Mbps WAN port
- Button: WPS/Wi-Fi Button, Reset Button, Power On/Off Button
- External Power Supply: 9V/0.6A(EU), 9V/0.6A(US)
- Dimensions ( W x D x H ): 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
- Antenna: 2 × 2.4GHz Antennas, 1 × 5GHz Antenna
Wireless Features
- Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
- Frequency: 2.4GHz and 5GHz
- Signal Rate: 5GHz: Up to 433Mbps, 2.4GHz: Up to 300Mbps
Reception Sensitivity:
5GHz:
11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm;
11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9:
-62dBm
2.4GHz:
11g 54M: -76dBm11n; HT20 MCS7: -73dBm;
11n HT40 MCS7: -71dBm
Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Transmission Power:
CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
Software Features:
Quality of Service: WMM, Bandwidth Control
Management: Access Control, Local Management, Remote Management
Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, Comexe, NO-IP
VPN Pass-Through: PPTP, L2TP, IPSec
Access Control: Parental Control, Local Management, Control, Host List, Access Schedule, Rule Management
Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
Protocols: Supports IPv4 and IPv6
Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 1
