FEATURES

Gigabit Wi-Fi 6 Speed for 4K Streaming 3000Mbps Dual Band Wi-Fi for faster browsing, streaming and downloading, all at the same time
Flexible Deployment Supports Passive PoE to carry electrical power and data simultaneously
Multiple Modes Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs
Boosted Coverage Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals
Captive Portal Offers a designed portal page for heightened security and marketing

SPECIFICATIONS

HARDWARE FEATURES
Interface: 1 Gigabit Port (Supports Passive PoE)
Button: Power On/Off Button, WPS Button, Reset Button
External Power Supply: 48V/0.5A
Dimensions ( W x D x H ): 240×165×43.6mm
Antenna: 4 Fixed High Performance Antennas

WIRELESS FEATURES
Wireless Standards: IEEE802.11b/g/n/ax 2.4GHz, IEEE 802.11a/n/ac/ax 5GHz
Frequency: 2.4GHz and 5GHz
Signal Rate: 2402Mbps at 5GHz, 574Mbps at 2.4GHz
Reception Sensitivity 5 GHz:
- 11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
- 11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
- 11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
- 11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
2.4 GHz:
- 11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
- 11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm
Wireless Functions: Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control
Wireless Security: WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions
Transmission Power: FCC: <23dBm(2.4GHz), <22dBm(5GHz)

SOFTWARE FEATURES
Quality of Service: WMM
Operating Modes: Access Point, Range Extender, Client, Multi-SSID
System Tools: SNMP, Ping Watchdog
DHCP: Server, DHCP Client List
Protocols: IPv4, IPv6

OTHERS
Certification: FCC, RoHS
System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Environment: Operating Temperature: 0°C ~ 40°C
Operating Humidity: 10%~90% non-condensing
