TP-Link CPE605 5GHz 150Mbps 23dBi Outdoor CPE

MAXtream TDMA

23dBi directional antenna and professional structural stability for long-distance outdoor Wi-Fi transmission.

Professional-standard 23dBi Directional Antenna for Long-range Wireless Transmission

With 23dBi high-gain directional Cassegrain antenna and dedicated metal reflector, the CPE605 provides excellent beam directivity, improved latency and noise immunity. Professional performance, coupled with user-friendly design, makes the 5GHz 150Mbps 23dBi Outdoor CPE605 an ideal choice and cost-effective solution for outdoor wireless networking transmission up to 20 km.

Stable Structural Design and Flexible Installation

• Snap-lock parts make assembly simple and convenient
• Pole mount kits and the freedom of three-axis alignment facilitate flexible installation
• Sturdy design ensures stability in windy conditions

Compact and Lightweight Packaging

Small and lightweight boxes benefit shipping, logistics and retail.

Specifications:

HARDWARE FEATURES

Processor: Qualcomm 560MHz CPU, MIPS 74Kc

Memory: 64MB DDR2 RAM,8MB Flash

Interface: 1 10/100: Mbps Shielded Ethernet Port (LAN/POE), 1 Reset Button

Power Supply: Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)

Voltage range: 16-27VDC

Dimensions ( W x D x H ): 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)

Antenna Gain: 23dBi

Antenna Beamwidth: 7°(Azimuth), 10°(Elevation)

Protection: 15KV ESD Protection, 6KV Lightning Protection

Enclosure Material: Outdoor PC stabilized plastic

Weatherproof: IP65 water and dust proof design

WIRELESS FEATURES

Wireless Standards: IEEE 802.11a/n

Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled)

Wireless Speeds:

• Up to 150Mbps (40MHz,Dynamic)
• Up to 72.2Mbps (20MHz,Dynamic)
• Up to 36.1Mbps (10MHz,Dynamic)
• Up to 18.05Mbps (5MHz,Dynamic)

Frequency: 5.15~5.85GHz *Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.

Transmission Power: Max. 23dBm (Adjustable power by 1dBm)

SOFTWARE FEATURES

IPv6: Yes

Network Configuration

• WAN: Static/Dynamic/PPPoE/L2TP/PPTP
• LAN: Static/Dynamic/DHCP
• Forwarding: ALG/UPnP/Virtual Server/Port Trigger
• Security: SPI Firewall/ Ping Forbidden/DoS Protection
• Access Control
• Static Routing
• Bandwidth Control
• IP & MAC Binding

Wireless Configurations

• Pharos MAXtream TDMA Technology
• Selectable Channel Width: 5/10/20/40MHz
• Auto Channel Selection
• Transmit Power Control
• Dynamic Frequency Selection(DFS)
• WDS Enable/Disable
• Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
• 64/128/152-bit WEP Encryption
• SSID Broadcast Enable/Disable
• Multi-SSID with VLAN Tagging(AP Mode only)
• Distance/ACK Timeout Setting
• Wireless MAC Address Filter
• Wireless Advanced:
• Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
• Long Range PtP

Management Features

• Discovery and Remote Management via Pharos Control application
• HTTP/HTTPS Web-based management
• System log
• SNMP Agent(v2c)
• Ping Watch Dog
• Dynamic DDNS
• SSH Server

System Tools

• Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
• Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
• Spectrum Analyzer
• Speed Test
• Ping
• Traceroute
• Antenna Alignment

System-level Optimizations: Optimized IGMP Snooping/Proxy for multicast applications
