OverviewEAP610-OutdoorAX1800 Indoor/Outdoor WiFi 6 Access PointSuperior WiFi 6 Speeds:Delivers dual band speeds of up to 1.8 Gbps powered by the latest WiFi 6 technology.xHigher Network Efficiency:Enjoy faster speeds on more devices with less lag with OFDMA and MU-MIMO.Long-Range Coverage:Dedicated high-power amplifier and professional antennas with an IP68 weatherproof enclosure.Omada Mesh Technology:Enables wireless connectivity between access points for extended range and flexible deployment.xxStay Smooth with Seamless Roaming:Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points.xxPoE Powered:Supports both 802.3at PoE and Passive PoE (adapter included) power supply for flexible installation.Centralized Cloud Management:Omada SDN integration manages the whole network locally or from the cloud via web UI or the Omada app.xxSpecificationsHARDWARE FEATURESInterface 1× Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE)Button ResetPower Supply 802.3at PoE 48V Passive PoE (PoE Adapter Included - For Dry Indoor Use Only)Max. Power Consumption EU: 13.2W (802.3at PoE or Passive PoE) US: 14.7W (802.3at PoE or Passive PoE)Dimensions ( W x D x H ) 4.2 × 2.2 × 11.1 in (106.5 × 57 × 281 mm)(without antenna & mounting kit)Antenna 2.4 GHz: 2× 4 dBi 5 GHz: 2× 5 dBiWeatherproof Enclosure IP68Mounting Pole/Wall Mounting (Kits included)WIRELESS FEATURESConcurrent Clients 250+ Wireless Standards IEEE 802.11ax/ac/n/g/b/aFrequency 2.4 GHz, 5 GHzSignal Rate 802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80) 802.11ac: 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80) 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40) 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 MbpsWireless Functions 1024-QAM 4× Longer OFDM Symbol OFDMA Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS (WMM) MU-MIMO Omada Meshxx Seamless Roaming(802.11k/v/r)xx Band Steering Load Balance Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/ClientWireless Security Captive Portal Authenticationxx Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/EnterpriseTransmission Power CE:
