- Professional centralized management for Wi-Fi network
- Free cloud access to manage from anywhere, anytime
- PoE (802.3af/802.3at) supported for easy installation
- Industry leading hardware design with powerful chipset, durable metal casing, and USB port for auto backup
- Omada App for a convenient management
- Secure guest network with multiple login options(Facebook Wi-Fi, SMS login, Vourcher)
HARDWARE FEATURES
Interface 10/100Mbps Ethernet Portx2
USB 2.0 Portx1
Micro USB Portx1
Power Supply 802.3af/at PoE or Micro USB DC 5V/Minimum 1A
Dimensions ( W x D x H ) 3.9×3.9×1.0in. (100×98×25mm)
FEATURES
Wireless Fuction L3 Management
Multi-SSID
Load Balance
Band Steering
Airtime Fariness
Beamforming
Rate Limit
Wireless Schedule
QoS
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
AP Management Automatic Discovery
Unified Configuration
Reboot Schedule
Batch Firmware Upgrade
LED ON/OFF
Authentication Captive Portal
Management Features
Omada App Yes
Centralized Management Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers
Up to 1,000 Clients
Note: Please refer to www.tp-link.com/en/business-networking/all-omada/ to find all the device models supported by OC200
Cloud Access Yes
L3 Management Yes
Multi-site Management Yes
Management Features Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
OTHERS
Certification CE, FCC, RoHS
Package Content Omada Cloud Controller
OC200
Quick Installation Guide
Ethernet Cable
System Requirements Microsoft Windows 10, 8, 7,Vista , XP or MAC OS, NetWare , UNIX or Linux
Environment Operating Temperature: 0 ~40 (32 ~104 )
Storage Temperature: -40 ~70 (-40 ~158 )
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
What's in the box
Omada Cloud Controller OC200
Quick Installation Guide
Ethernet Cable
