FEATURES

BE5000 Dual-Band Wi-Fi 7 (4,324Mbps on 5.0GHz plus 688Mbps on 2.4GHz)
1× 2.5GbE port unlocks the full potential of Wi-Fi 7
240MHz bandwidth enables many more simultaneous transmissions
Multi-Link Operation and Multi-RUs ensure the high-performance of your network
Advanced functions centralised management, mesh and seamless roaming

SPECIFICATIONS

HARDWARE FEATURES
Interface: 1× 2.5G Ethernet Port
Button: Reset
Power Supply: 802.3at PoE or 12V 1.5A DC (Power Adapter is Not Included)
Max. Power Consumption:
- 17.8W (PoE)
- 14W (DC)
Dimensions (W × D × H): 160 × 160 × 36.7mm
Antenna:
- 2.4GHz: 2× 4dBi
- 5.0GHz: 2× 5dBi
Mounting: Ceiling / Wall-Mounting / Junction Box (Kits Included)

WIRELESS FEATURES
Coverage: 140m²
Concurrent Clients: 250+
Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
Frequency: 2.4GHz and 5.0GHz
Signal Rate: 688Mbps (2.4GHz) + 4,324Mbps (5.0GHz)

WIRELESS FUNCTIONS
MLO
4K-QAM
Seamless Roaming
MU-MIMO
EHT240
Mesh
OFDMA
Load Balance
Band Steering
Beamforming
Airtime Fairness
Multiple SSIDS: 16× (8× on each Band)
Wireless Schedule
Reboot Schedule
QoS (WMM)
Rate Limit
Static IP / Dynamic IP
RADIUS Accounting
MAC Authentication

WIRELESS SECURITY
Captive Portal Authentication
Access Control
Maximum Number of MAC Filter: 4,000
Wireless Isolation Between Clients
VLAN
Rogue AP Detection
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power:
- <25dBm (2.4GHz)
- <25dBm (5.0GHz, Band 1 & Band 4)
- <24dBm (5.0GHz, Band 2 & Band 3)

MANAGEMENT FEATURES
Omada App: Yes
Centralised Management:
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
Cloud Access: Yes
Require the Use of an OC300, OC200, Omada Software Controller or an Omada Cloud-Based Controller
Email Alerts: Yes
LED ON/OFF Control: Yes
Management MAC Access Control: Yes
SNMP: v1, v2c, v3
System Logging Local / Remote Syslog: Yes
Web-Based Management: Yes

OTHERS
Certification: CE, FCC, RoHS, IC
Environment:
- Operating Temperature: 0~40°C
- Storage Temperature: -40~70°C
- Operating Humidity: 10~90% Non-Condensing
- Storage Humidity: 5~90% Non-Condensing
