TP-Link 300Mbps Wireless N Speed Router - 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work, IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming, Compatible with IPv6 (Internet Protocol version 6)
Product Overview
The Wi-Fi Router TL-WR820N supports Wi-Fi 4 (802.11n/b/g) on the 2.4 GHz band with speeds up to 300 Mbps, ideal for 2-bedroom houses using two fixed antennas. It offers multiple operating modes including router, access point, range extender, and WISP, with robust security features such as WPA3 encryption, SPI firewall, and guest network support. The compact router includes one 10/100 Mbps WAN port and two LAN ports, with easy setup via the Tether app and compatibility with various internet protocols for versatile home network management.
Features
300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work
IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
Compatible with IPv6 (Internet Protocol version 6)
Guest Network provides separate access for guests while securing the host network
Parental Controls manage when and how connected devices can access the internet
Security protocols protect your home network with firewalls and wireless encryption
Specifications
Product Code: TL-WR820N
Description: TP-Link 300Mbps Wireless N Speed Router
Standards and Protocols
Wi-Fi 4: IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds: 2.4 GHz 300 Mbps (802.11n)
WiFi Range: 2× Fixed Antennas
WiFi Capacity: Legacy
Working Modes
Router Mode
Access Point Mode
Range Extender Mode
WISP Mode
Network Security
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network: 1× 2.4 GHz Guest Network
WiFi Encryption
WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)
Processor: Single-Core CPU
Ethernet Ports
1× 10/100 Mbps WAN Port
2× 10/100 Mbps LAN Ports
Buttons: Reset Button
Power: 5 V 0.6 A
Protocols: IPv4, IPv6
Parental Controls: URL Filtering, Time Controls
WAN Types
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service: QoS by Device
NAT Forwarding
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP
Address Reservation
DHCP Client List
Server
DDNS: NO-IP, DynDNS
Management Features: Tether App, Webpage
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Certifications: FCC, CE, RoHS
