TP-Link VIGI InSight S245 4MP Full-Colour Dome Network Camera - 2.8mm
Smarter Surveillance. Full Colour Clarity.
Capture every detail with vivid 4MP imaging and full-colour night vision, ensuring clear footage day and night without relying on infrared. The VIGI InSight S245 combines intelligent human and vehicle detection with advanced video analytics to minimise false alerts and improve monitoring accuracy. Built with an IP67 weatherproof and IK10 vandal-proof design, it delivers reliable performance in demanding outdoor environments. Efficient H.265+ compression reduces storage and bandwidth usage, while seamless remote access via the VIGI app keeps you connected and in control from anywhere.
FEATURES
4MP Ultra HD Imaging - High-resolution video capture for clear and detailed surveillance
Full-Colour Night Vision - Maintains vivid colour footage in low-light conditions without IR-only limitations
Smart Human and Vehicle Detection - Accurate classification reduces false alarms and improves monitoring efficiency
IK10 Vandal-Proof and IP67 Weatherproof - Built for harsh environments with strong impact and weather resistance
H.265+ Video Compression - Reduces bandwidth and storage requirements while maintaining video quality
Active Deterrence Support - Enhances security response with intelligent alert features
Two-Way Audio - Built-in microphone and speaker for real-time communication
Remote Monitoring via VIGI App - Real-time viewing, playback and management from anywhere
SPECIFICATIONS
Sensor: 1/2.7" Progressive Scan CMOS
Minimum Illumination: 0.005 Lux / 0 Lux with IR
Lens Options: Fixed 2.8mm
Aperture: F1.6
Field of View: 110° (H) / 58.1° (V) / 133.5° (D)
DORI: Detect 64m / Identify 6m
Max Resolution: 2688 × 1520
Frame Rate: up to 30fps
Video Compression: H.265+ / H.265 / H.264+ / H.264
Bit Rate:
- Main Stream: 256Kbps6Mbps
- Sub Stream: 64Kbps512Kbps
Streams: 1× Main + 1× Sub
IR LEDs: 2×
White LEDs: 2×
Night Vision Distance: up to 30m
Modes: Auto / Scheduled / Always On / Off
WDR: 120dB
SNR: 52dB
Enhancements: BLC, 3D DNR, HLC, SmartIR
Image Adjustments: Brightness, Contrast, Saturation, Sharpness
Privacy Mask: up to 4× Zones
Human and Vehicle Classification
Smart Detection:
- Line Crossing
- Intrusion
- Region Enter / Exit
- Loitering
- Object Removal / Abandonment
- Scene Change
- Abnormal Sound Detection
Two-Way Audio: Yes
Microphone: Built-in
Speaker: Built-in
Audio Compression: G.711
Protocols: TCP/IP, HTTP(S), DHCP, RTSP, NTP, FTP, IPv4/IPv6
ONVIF: Profile G / S / T
Live View: up to 3× Main + 3× Sub Streams
Management: VIGI App, Web UI, VMS, Cloud
Port: 1× RJ45 (10/100Mbps, PoE)
Storage: microSD (up to 512GB)
Button: Reset
DC Input: 12V ±5% (Max. 10.54W)
PoE: 802.3af/at (Max. 12.52W)
Protection: IP67 / IK10
Material: Metal
Operating Temperature: -30~60°C
Humidity: 95% (Non-Condensing)
Dimensions: 122 × 122 × 89mm
Weight: 0.62kg
