TP-Link 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router - WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac). Ethernet LAN interface type: Gigabit Ethernet, Networking standards: IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n, Ethernet LAN data rates: 10,100,1000 Mbit/s. 3G standards: HSPA,HSPA+,UMTS, 4G standard: LTE, UMTS bands supported: 850,900,2100 MHz. Security algorithms: 64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK, Firewall security: Domain Filter, IP, MAC Address Binding.
Product Overview
The TP-Link 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router delivers lightning-fast 4G+ speeds of up to 300 Mbps with plug-and-play SIM card compatibility in over 100 countries. It features MU-MIMO technology for efficient multitasking, dual-band Wi-Fi, and full gigabit ports for high-speed wired connections. With support for TP-Link OneMesh and external LTE antennas, it ensures wide coverage, stable connectivity, and easy management via the Tether app.
Specifications
Product Code: ARCHER_MR600
Description: TP-Link 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router ARCHER MR600
Hardware Features
Interface: 1 × 10/100/1000 Mbps LAN/WAN Port
3 × 10/100/1000 Mbps LAN Ports
1 × Micro SIM Card Slot
Button: WPS Button, Reset Button, WiFi On/Off Button, Power On/Off Button
External Power Supply: Power Adapter: Input Power 100-240v~50/60 Hz 0.6A
Output parameter 12VDC 1.5A
Dimensions ( W x D x H ): 9.0×6.3×1.5 in ( 229×160×37 mm)
Antenna: 2 × Detachable 4G LTE Antennas
Wireless Freatures
Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency: 2.4 GHz and 5 GHz
Signal Rate: 300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Reception Sensitivity: 5 GHz: 11a 54M: -74 dBm
11ac HT20: -66 dBm
11ac HT40: -63 dBm
11ac HT80 : -59 dBm
11n HT20: -73 dBm
11n HT40: -70 dBm
2.4 GHz: 11g 54M: -74 dBm
11n HT20: -72 dBm
11n HT40: -69 dBm
Transmit Power: < 20 dBm (2.4 GHz), < 23 dBm (5 GHz) Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics WAN Failover: Yes Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Network Type: 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) 3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)
Software Features
Quality of Service: Bandwidth Control
Security: DoS, IPv4 SPI Firewall, IPv6 Firewal, IP and MAC Address Binding, Access Control
WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management: TP-Link Cloud, Local Management, Remote Management
DHCP: Server, DHCP Client List, Address Reservation
Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: TP-Link, DynDns, NO-IP
VPN: PPTP VPN, IPSec VPN , OpenVPN
Access Control: Parental Control, Local Management Control
Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter,
IP and MAC Address Binding
Protocols: IPv4, IPv6
Guest Network: 2.4 GHz Guest Network x 1, 5 GHz Guest Network x 1
