Traco Power (TEN 5-2412WI) Isolated Through Hole DC/DC Converter 12V, 500mA

Isolated Through Hole DC/DC Converter, ITE, 4:1, 5 W, 1 Output, 12 V, 500 mAProduct InformationPower Supply Approvals: ITEOutput Power Max: 5WInput Ratio: 4:1Output Voltage - Output 1: 12VOutput Current - Output 1: 500mANo. of Outputs: 1 OutputIsolation Voltage: 1.5kVInput Voltage DC Min: 9VInput Voltage DC Max: 36VDC / DC Converter Output Type: FixedInput Voltage DC Nom: 24VDC / DC Converter Type: DIPDC / DC Converter Mounting: Through HoleWidth: 20.3mmHeight: 10.2mmDepth: 31.8mmProduct Range: TEN 5WI SeriesProduct OverviewThe TEN 5-2412WI is a 1-output board-mount Isolated DC/DC Converter Modulefeatures ultra wide input voltage ranges of 9 to 36VDC. It comes withindustry-standard footprint. A high efficiency allows -40 to +70°C operationambient temperatures at full load. It provides over voltage protection andshort-circuit protection.Ultra-wide 4:1 input range83% Efficiency1500VDC I/O isolation±0.02%/K Temperature coefficient100µF Maximum capacitive load450kHz Switching frequencyBuilt-in filterFull SMD designExcellent load and line regulationApplicationsPower Management, Sensing & Instrumentation, Communications & Networking,Industrial
