TRADEWELD CUT 40H PLASMA CUTTER
CHEAPEST IN SOUTH AFRICA
The welding machine is a rectifier adopting the most advanced inverter technology. The inverter gas-shielded welding power source utilises a high power component called MOSFET to transfer 50/60HZ frequency up to 100KHZ, then reduces the voltage and commutate, and output high power voltage via PWM technology. Because of the great reduction of the main transformer's weight and volume, the efficiency increase by 30%.
The power source can offer a stronger, more concentrated and stable arc.
The CUT 40H can be used to cut:
1. Mild Steel 4. Brass
2. Stainless Steel 5. Copper
3. Aluminium
MAIN TECHNICAL DATA
Power Voltage (V) | 1 Phase 220V (15%) |
Rated Input Power (KVA) | 6.6 |
No-Load Voltage (V) | 230 |
Rated Input Current (A) | 30 |
Rated Output Voltage (V) | 96 |
Duty Cycle | 60% |
Pilot Arc Cycle | HF Oscillating |
Cutting Nozzle Diameter | 1.0 |
Pressure Of Air Compressor (kg) | 4-5 |
Thickness (mm) | 1-12 |
Weight (kg) | 9 |
Dimensions (mm) | 485 x 195 x 320 |
