Trendnet TPE-104S Power over Ethernet Splitter is an essential tool for integrating non-PoE devices into a PoE-powered network. This compact device splits a single PoE signal into separate power and data outputs, making it ideal for remote installations where standard power outlets are unavailable. With adjustable output voltage options of 5V, 7.5V, 9V, or 12V, the TPE-104S supports a wide range of networked devices such as IP cameras, access points, and VoIP equipment.
This brand-new unit simplifies cabling, reduces installation costs, and extends deployment flexibility by enabling non-PoE devices to operate up to 100 meters from a PoE switch or injector. Built-in short circuit protection helps safeguard your network equipment during operation.
Key Features & Benefits:
Converts PoE to Non-PoE Splits data and power for easy integration of non-PoE devices into PoE networks.
Up to 100m PoE Transmission Extend power and data across long distances via standard Ethernet cable.
Selectable Output Voltages DIP switch lets you choose from 5V, 7.5V, 9V, or 12V output to match device requirements.
Cost-Saving Deployment Avoids the need for nearby power outlets in remote or hard-to-wire locations.
Compact and Lightweight Fits easily in tight spaces and mounts near target devices.
Short Circuit Protection Protects valuable equipment from power surges and electrical damage.
Ideal Uses:
Remote IP Cameras Power non-PoE surveillance cameras in outdoor or distant areas.
Wireless Access Points Deliver stable power and connectivity to ceiling or outdoor access points.
Retail & POS Systems Perfect for kiosks or terminals where standard power outlets are limited.
Networking in Warehouses or Industrial Areas Extend power to non-PoE devices in rugged environments.
Specifications
Condition:
Device with no signs of previous use. Device has been extensively tested and is 100% Functional.
Manufacturer & Model:
Trendnet TPE-104S
Form Factor:
Power over Ethernet Splitter
Standards Compliance:
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
Ports & Connectivity:
1 x 10/100Mbps Data + Power In (PoE In)
1 x 10/100Mbps Data Out
1 x 5.5mm Power Output Port
1 x DIP Switch (Adjustable Output Voltage: 5V / 7.5V / 9V / 12V)
Power Specifications:
Power Input: 48VDC @ 0.38A
Power Output:
5V @ 2A
7.5V @ 2A
9V @ 1.7A
12V @ 1.2A
Max Power Consumption: 0.3W
Cabling:
Network Media: Cat. 5/5e UTP/STP, up to 100 meters
Jumper Cables:
1 x 2.0 x 2.0mm
1 x 2.5 x 2.0mm
Physical Specifications:
Dimensions: 70 x 45 x 25 mm (2.75 x 1.8 x 1 in.)
Weight: 45g (1.6 oz.)
Environmental Conditions:
Operating Temp: 0°C ~ 45°C
Storage Temp: -20°C ~ 90°C
Humidity: Max. 90% (non-condensing)
Certifications:
CE, FCC
Operating System:
Not Applicable (PoE Accessory)
Warranty & Inclusions
Warranty: 12-Month Carry-In Warranty
What's in the Box?
Trendnet TPE-104S PoE Splitter
2 x Jumper Cables (2.0 x 2.0mm & 2.5 x 2.0mm)
Quick Installation Guide
Power Non-PoE Devices Seamlessly integrate legacy hardware into modern PoE environments.
Extended Reach Up to 100 meters of distance from the PoE source.
Flexible Voltage Output Supports a wide range of low-voltage network devices.
Installation Simplified Compact size and included jumper cables for plug-and-play deployment.
