UBIQUITI UCG-MAX-EU COMPACT 2.5G CLOUD G

Ubiquiti UCG-MAX UniFi Ultra Max - Multi-WAN Cloud Gateway Max

Overview:

Gateway Max
UXG-Max
Compact, multi-WAN UniFi gateway with full 2.5 GbE support for high-performance networking at small-to-medium sites.

• Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
• Up to 1.5 Gbps routing with IDS/IPS
• (1) 2.5 GbE WAN port
• (4) 2.5 GbE LAN ports, including (1) remappable to WAN
• USB-C powered (adapter included)
• Managed with UniFi Network 8.1.113 and later

Specifications:

Specifications
Product Code	UCG-MAX-EU
Mechanical
Dimensions	141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Weight	520 g (1.1 lb)
Enclosure material	Polycarbonate
Resistance	IK04
Hardware
Processor	Quad-core ARM Cortex -A53 at 1.5 GHz
Memory information	2 GB DDR4
Management interface	Ethernet
	Bluetooth
Networking interface	LAN:
	(4) 2.5 GbE RJ45 ports
	WAN:
	(1) 2.5 GbE RJ45 port
IDS/IPS throughput	1.5 Gbps
Power method	USB type C (5V/3A)
Supported voltage range	100-240V
Max. power consumption	9.6W
LED	Ethernet
	White: link/activity
Button	(1) Factory reset
Ambient operating temperature	-10 to 40° C (14 to 104° F)
Ambient operating humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
Gateway Features
Performance	WiFi QoS with UniFi APs
	Application, domain, and country-based QoS
	Application and device type identification
	Internet quality and outage reporting
Next-generation security	Application-aware firewall rules
	Signature-based IPS/IDS threat detection
	Content, country, domain, and ad filtering
	VLAN/subnet-based traffic segmentation
	Full stateful firewall
Advanced networking	License-free SD-WAN
	WireGuard, L2TP and OpenVPN server
	OpenVPN client
	OpenVPN and IPsec site-to-site VPN
	One-click Teleport* and Identity Enterprise VPN
	Policy-based WAN and VPN routing
	DHCP relay
	Customizable DHCP server
	IPv6 ISP support
	*When paired with a CloudKey or Official UniFi Hosting.
	**When paired with a CloudKey.
Application Requirements
UniFi Network	Version 8.1.113 and later
