Ubiquiti UISP-S-PRO 24-port GbE Managed Switch with 16x PoE and 4x SFP+ ports

220W (27V) PoE switch with 24x GbE RJ45 ports, which includes 16-ports with 27V passive PoE and 4x 10G SFP+ ports.

Features

• 24x GbE RJ45 ports, including 16-ports with 27V passive PoE output
• 4x SFP+ ports
• 220W (27V) total PoE availability, 15W/port (2-pair) / 30W/port (4-pair)
• Port isolation, speed limiting, and DHCP snooping functionality
• 1.3" LCM color touchscreen
• Additional Power TransPort input for DC redundancy
• Standalone management through local web interface (Available for switches updated to version 1.6.0 and later.) and UISP Application integration

Technical Specifications

Networking interface

• 24x GbE RJ45 LAN ports (includes 16x PoE output ports)
• 4x 1/10G SFP+ ports

Management interface: Ethernet In-band, Bluetooth
Total non-blocking throughput: 64 Gbps
Switching capacity: 128 Gbps
Forwarding rate: 95.23 Mpps
Power method

• Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz
• Power TransPort DC input 27V DC, 9.3A

Power supply: AC/DC, Internal, 250W
Supported voltage range: 100—240V AC
Max. power consumption: 30W (Excluding PoE output)
ESD/EMP protection: Air: ± 15 kV, contact: ± 8 kV
LCM display: 1.3" touchscreen

PoE
PoE interface: 16x 27V passive PoE: 2-pair (Pins 4, 5+/7, 8-) or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16
Total available PoE: 220W
Max. passive PoE wattage per port: 30W/27V DC
Passive PoE voltage range: 27V DC
