Ubiquiti Unifi 7 Dual-band Wi-Fi 7 In-Wall Access Point U7-IW

Wall-mounted WiFi 7 AP with 4 spatial streams and an integrated 2.5 GbE PoE switch designed for hospitality environments.

• Note: PoE+ input required for single-port PoE output.

Technical Specification

Interface Ports: 3x 2.5 GbE RJ45 ports

Built-In Switch: 1x PoE+ input and 1x PoE output

WiFi Standard: Wi-Fi 7

Spatial Streams: 4

MIMO

• 5 GHz: 2 x 2 (DL/UL MU-MIMO)
• 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)

Max. Data Rate

• 5 GHz: 4.3 Gbps (BW240)
• 2.4 GHz: 688 Mbps (BW40)

Supported Data Rates

• 802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
• 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
• 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
• 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Coverage Area: up to 115 m² (1,250 ft²)

Max. Client Count: 200+

Uplink: 2.5 GbE

Mounting: Wall (Metal Wall Mount Included)

Power Method

• PoE
• PoE+ (Required for PoE output)

Max. Power Consumption: 13W (Excluding PoE output)

Supported Voltage Range: 42.5—57V DC

Mounting: Wall (Metal Wall Mount Included)

Dimensions: 137 x 98.7 x 30.2 mm

Weight: 400 g
