Show Room Demo (Open Box)
Description
Ubiquiti's UAP-ACM-DA, UniFi Antenna, model UMA-D, is an optional mesh antenna designed to work with the UniFi AC Mesh AP, model UAP-AC-M. With dual-band support, the UMA-D expands range coverage and provides customized pattern shaping. The antenna is optimised for 802.11ac, the UMA-D offers a high efficiency directional radiation pattern with dual polarity. It's weather-resistant enclosure is made of UV-stabilised plastic, thus making it ideal for indoors or outdoor use.
Specifications:
- Enclosure: Outdoor UV Stabilized Plastic
- RF Connections: (2) RP-SMA
- Supported Frequency Range: 2.4 - 2.5GHz, 5.1 - 5.9 GHz
- HPOL Beam-width 2.4 GHz: 90-degrees
- HPOL Beam-width 5GHz: 45-degrees
- VPOL Beam-width 2.4 GHz: 90-degrees
- VPOL Beam-width 5GHz: 45-degrees
- Elevation Beam-width 2.4 GHz: 90-degrees
- Elevation Beam-width 5GHz: 45-degrees
- Maximum VSWR: 2:1br> Polarization: Dual-Linear
- Cross-Pol Isolation 2.4 GHz: 25 dB
- Cross-Pol Isolation 5GHz: 30 dB
- Antenna Gain 2.4 GHz: 10 dBi
- Antenna Gain 5GHz: 15 dBi
- Mounting: Wall/Pole (Kits Included)
- Dimensions: 201.3 x 128.0 x 32.5 mm
- Weight: (with Mount) 480 g
- Weight: (without Mount) 400 g
