Ubiquiti's U7-LITE is a Dual-Band WiFi 7 access point featuring high gain integrated antennas and 1x 2.5Gbps Ethernet port. It delivers an aggregate data rate of up to 5Gbps over its 5GHz (2x2 MU-MIMO) and 2.4GHz (2x2 MU-MIMO) bands.
It can be configured and managed with the UniFi Network Application.
*Note: PoE injector not included.
The Ubiquiti U7-Lite is a compact, high-performance Wi-Fi 7 access point designed for
seamless connectivity in small to medium-sized environments. It supports dual-band
Wi-Fi 7 (2.4 GHz and 5 GHz) with speeds up to 5.3 Gbps, utilizing 2×2 MU-MIMO and
OFDMA for efficient multi-device handling. The U7-Lite features a 2.5 Gbps Ethernet
port with PoE support (802.3af) for easy installation and power delivery. With a sleek,
unobtrusive design, it supports advanced Wi-Fi 7 features like 4K-QAM, 320 MHz
channel bandwidth, and multi-link operation (MLO) for enhanced performance and
reliability. Ideal for modern networks, it ensures high-speed, low-latency wireless
Mechanical
WiFi Standard WIFi 7 - Spatial Streams 4
Coverage Area 115 m (1,250 ft ) Max. Client Count 200+
Uplink 2.5 GbE
Mounting Locations Ceiling, wall
Performance
MIMO
5 GHz 2.4 GHz 2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz 4.3 Gbps (BW240)
2.4 GHz 688 Mbps (BW40)
Antenna Gain
5 GHz 5 dBi
2.4 GHz 4 dBi
Max. TX Power
5 GHz 24 dBm
2.4 GHz 23 dBm
Max. BSSIDs 8 per Radio
Features
Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)
Captive Hotspot Portal
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN
Software - Application Requirements
UniFi Network UniFi OS Version 9.0.114 and later
OS version 10.20.2 and later
Android version 10.21.7 and later
Hardware
Max. Power Consumption 13W
Supported Voltage Range 42.5-57V DC
Networking Interface (1) 2.5 GbE RJ45 port
Weight 313 g (11 oz)
Management Ethernet
Enclosure Material UV-stabilized polycarbonate
Mount Material UV-stabilized polycarbonate, galvanized steel
LEDs - System White/Blue
Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160,
EHT 20/40/80/160/240 (MHz)
