Ugreen Maxidok 10-in-1 Thunderbolt 5 Docking Station 75795F
The UGREEN Revodok Maxidok 10-in-1 Thunderbolt 5 Docking Station transforms one compatible laptop connection into a versatile desktop workstation for demanding creative, business and productivity setups. It combines high-bandwidth Thunderbolt 5 connectivity, multi-display support, fast USB data transfer, card readers, wired networking and up to 100W laptop charging in a compact aluminium enclosure.
Key Features:
- Thunderbolt 5 connectivity provides bandwidth of up to 120Gbps for compatible high-performance storage, display and peripheral workflows.
- Supports up to two 8K displays on compatible Windows systems or two 6K displays on compatible macOS systems.
- Three USB-A 10Gbps ports provide fast connections for storage devices and other USB peripherals.
- Supplies up to 100W of power to a compatible host laptop from the included 140W power system.
- Integrated SD and microSD card readers support transfer speeds of up to 170MB/s.
- Gigabit Ethernet provides a stable 10/100/1000Mbps wired network connection.
- Aluminium construction and an internal heatsink support quiet, reliable heat dissipation.
High-Bandwidth Thunderbolt 5 Connectivity
The Thunderbolt 5 host connection provides the bandwidth needed for large file transfers, high-resolution displays and performance-focused peripherals. Two downstream Thunderbolt 5 ports allow compatible displays, storage devices and accessories to be added to the workstation, with up to 15W available from each downstream port.
Flexible Multi-Display Workspaces
Two downstream Thunderbolt 5 ports and a dedicated DisplayPort 2.1 connection provide flexible options for building an extended desktop. Compatible Windows systems can support up to two 8K displays, while compatible macOS systems can support up to two 6K displays. Available resolutions, refresh rates and extended-display configurations depend on the host computer, operating system and connected displays.
Fast Access to Peripherals and Media
Three 10Gbps USB-A ports accommodate external drives, keyboards, mice and other everyday peripherals. The integrated SD and microSD card readers provide convenient access to compatible camera and mobile storage media at speeds of up to 170MB/s, while Gigabit Ethernet supports consistent wired networking for downloads, collaboration and streaming.
Power for a Single-Cable Workspace
The docking station uses a 140W power adapter and can deliver up to 100W to a compatible host laptop. This helps keep the computer charged while the dock powers connected displays and peripherals, reducing the number of separate cables and adapters required on the desk.
Technical Specifications:
| Specification | Details |
| Brand | UGREEN |
| Product Range | Revodok Maxidok |
| Manufacturer Part Number | 75795F |
| Syntech SKU | U712-75795F |
| Product Type | 10-in-1 Thunderbolt 5 docking station |
| Colour | Space Grey |
| Total Ports | 10 |
| Host Connection | 1 × Thunderbolt 5 upstream port |
| Thunderbolt Outputs | 2 × Thunderbolt 5 downstream ports |
| Thunderbolt Bandwidth | Up to 120Gbps bandwidth boost |
| DisplayPort | 1 × DisplayPort 2.1 |
| USB Ports | 3 × USB-A, up to 10Gbps each |
| Network Connection | 1 × RJ45 Gigabit Ethernet port |
| Ethernet Speed | 10/100/1000Mbps |
| Card Readers | 1 × SD and 1 × microSD/TF, up to 170MB/s |
| Maximum Windows Display Support | Up to two 8K displays on compatible systems |
| Maximum macOS Display Support | Up to two 6K displays on compatible systems |
| Laptop Charging | Up to 100W to a compatible host device |
| Power Adapter Rating | 140W |
| Downstream Thunderbolt Power | Up to 15W per downstream Thunderbolt 5 port |
| System Compatibility | Compatible Thunderbolt and USB4 computers; available features depend on the host connection |
| Operating System Compatibility | Windows 11 version 23H2 or later; macOS 15 or later |
| Enclosure | Aluminium alloy with internal heatsink |
| Warranty | 24 months |
| EAN | 6941876283644 |
Compatibility Notes:
- The maximum display resolution and number of extended displays depend on the host computer, graphics hardware, operating system, cables and monitors.
- Thunderbolt video output uses USB-C connectors; monitors with HDMI or DisplayPort inputs may require a suitable USB-C video cable or adapter.
- The maximum charging rate depends on the power requirements and charging capabilities of the connected laptop.
- Full Thunderbolt 5 performance requires a compatible Thunderbolt 5 host computer.
What's in the Box:
- UGREEN Revodok Maxidok 10-in-1 Thunderbolt 5 Docking Station
Build a cleaner, high-performance workstation with the UGREEN Maxidok 10-in-1 Thunderbolt 5 Docking Station and add it to your cart today.
