Complete PCP connector setup, between your diving tank/carbon fiber, wrapped PCP tank and your rifle.
THIS IS A DIN CONNECTOR FITTING.
Rated maximum for 300 BAR / 30 mPa / 4350 PSI
The main body is entirely chrome plated w/ red painted tap that allows for the fitting to be hand-fixed into the scuba tank. Just tighten properly, no need for tool-fastening.
Affixed onto this main hull, you'll find the ?41.76mmoil-filled gauge w/ a brass male thread of?9.90mm 1/8" BSP
There is a bleeder valve, serrated, that screws open and shut. Please screw this open gradually when bleeding high pressure air out.
At the rear, there is a male quick filling plug which the connector hose runs from. Moreover, using this same plug but w/out the hose, conversely, you can use this station to fill your diving tank / PCP refill tank instead, however, please note that you'll need atleast a 220V HPA compressor and the refilling will have to occur in stages, not all at once. Please only run your compressor up to 60C and thus refill your tank in stages as is necessary.
The fittings on the hose come off and before using this station, you'll need to tighten your choice of fitting (as is appropriate to your PCP rifle) w/ use of PTFE / plumber's / threading tape and wrap tight coils around the threading, before screwing the fitting on. The provided quick coupler fitting should be compatible with a number of filling probes of certain PCP rifles, such as the NOVA VISTA HP-900, however, not all rifles.
The high pressure hose is thoroughly rated for 300 BAR applications, of German manufacture and has a steel armour caging aroun the entire extent of the hose. The hose itself measures in 500mm.
Comes prepacked in a flat-profiled carton box w/ flip-up lid.
Included, per summary, in this deal;
- 1x Filling station w/ bleeder valve, DIN coupled, male quick coupling plug
- 1x 300 BAR Oil-filled gauge
- 1x 500mm steel wire armoured 300 BAR connector hose
- 2x Brass female quick couplers / foster fittings that can detqach from the hose.
- 1x Bag of 5 spare seals / O-rings
