UNI-T UT89XD Professional 1000V Digital Multimeter (True RMS & LED Test)

UNI-T UT89XD Professional 1000V Digital Multimeter

The UNI-T UT89XD is a rugged, highly accurate 6000-count professional digital multimeter designed for industrial electricians, HVAC technicians, and advanced electronics engineers. Featuring True RMS measurements and a heavy-duty, dual-injection molded housing, the UT89XD stands out with its dedicated hardware LED test function, allowing you to diagnose discrete LEDs and multi-diode components with ease.

Key Features:
* **True RMS & 6000 Count Display:** Delivers precise, highly accurate readings on both linear and non-linear AC loads.
* **Specialized LED Testing:** Equipped with a dedicated high-voltage output mode (approx. 12V) to directly test and evaluate individual LEDs and LED strips.
* **Dual-Range NCV Sensing:** Built-in Non-Contact Voltage detection easily distinguishes between neutral and live wires using an interactive multi-color LED and buzzer system.
* **Industrial Grade Durability:** Wrapped in a heavy-duty, dual-injection anti-shock case with a 2-meter drop-proof survival rating.
* **Workplace Enhancements:** Features an automatic high-intensity LCD backlight, built-in flashlight, data hold, and clear audible continuity indicators.

Technical Specifications:
* **DC Voltage:** 600mV / 6V / 60V / 600V / 1000V ±(0.5%+2)
* **AC Voltage (True RMS):** 6V / 60V / 600V / 1000V ±(0.8%+5)
* **DC Current:** 60A / 6mA / 60mA / 600mA / 20A ±(0.8%+8)
* **AC Current (True RMS):** 60mA / 600mA / 20A ±(1.0%+12)
* **Resistance:** 600 / 6k / 60k / 600k / 6M / 60M ±(0.8%+3)
* **Capacitance:** 6nF / 60nF / 600nF / 6F / 60F / 600F / 6mF / 60mF / 100mF ±(2.5%+20)
* **Frequency Range:** 9.999Hz ~ 10MHz ±(0.1%+4)
* **Safety Rating:** CAT III 600V / CAT II 1000V
* **Power Supply:** 4 x 1.5V AAA Batteries (R03)

What's in the Box:
* 1 x UNI-T UT89XD Professional Multimeter
* 1 x Pair of Heavy-Duty Test Leads
* 4 x 1.5V AAA Batteries
* 1 x User Manual
