This item is sold brand new. It is ordered on demand from our supplier and is usually dispatched in 10 to 15 working days.
We urge you to please read shipping details before placing your order.
---------------------------------------
Features
1. This is the ultra power UP100AC duo dual port multi-chemistry battery charger.
It can be used worldwide with its auto switching power supply compatible with 100-240V.
2. It can also be powered by DC power allowing it to be used out in the field when a wall outlet is not available.
3. It has a high 100Watt max output! It has 2 independent charging ports.
4. Port 1 is capable of 100Watts and 10Amps max output and Port 2 is capable of 50Watts and 6Amps max output.
5. The charger can also be used as a power supply to power other devices up to 120Watts from the DC port!
6. Its a multi-chemistry charger so it can properly charge LiPo LiIon LiFe NiMH NiCd and Pb (lead acid) batteries.
7. It has a built in balancer for lithium type batteries. Each port has its own screen buttons 4mm output ports balance port temperature sensor port and PC link port. As an added bonus the charger has a 5V 2.1A USB port built into it to power and recharge your cell phone tablet etc.
8. High power output: This charger boasts 100Watts* of total charging power!
9. Convenience: Charge two batteries at once even if they are not the same chemistry voltage or capacity.
10. This charger has 2 individual charge ports and plugs directly into the wall. It also can be connected to a DC power source such as a 12V car battery or a DC power supply (DC power cable not included).
11. The charger also features LiPo Balance Charge LiPo fast charge LiPo storage and LiPo discharge modes.
12. Power supply: The charger can be used to power other DC devices such as chargers lathes lights etc.
13. It puts out a whopping 120Watts of power! Simply plug the charger into the wall and use the DC port on the right side of the charger to power your device.
14. Reliability: Ultra power is known for their great reliability. They use the best internal components and circuitry available to create long lasting products.
15. Lithium battery meter: Check the voltage of a Lithium batterys cells when plugged into the balance port. The screen will provide a readout of each cells voltage the total pack voltage as well as the highest and lowest cells.
16. Battery memory: You can program and store up to 10 different types of battery settings on each port. Then simply load the program to start charging using your stored battery settings.
17. Menu Options:
- LiPo Battery LiIon Battery LiFe Battery
- Balance Charge (Balances cells inside of battery while charging for optimal performance & safety)
- Charge
- Fast Charge
- Storage Mode (Brings battery to approx. half charge best for long term non-use)
- Discharge
- NiMH Battery NiCD Battery
- Manual Charge (Manually set charge amperage)
- Auto Charge (Set amperage limit charger will auto adjust)
- Discharge (Voltage adjustable from 0.1V-25.2V)
- Re-Peak (Top off the battery before use)
- Cycle (Cycle Charge/Discharge or Discharge/Charge up to 5 times)
- Pb (Lead Acid batteries such as the battery in your car)
- Charge
- Discharge
- Battery Memory (Store up to 10 battery settings that can be loaded to the charger)
- Battery Type (LiPo LiIon LiFe NiMH NiCD Pb)
- Battery Voltage
- Charge Current (Port 1: 0.1A-10.0A Port 2: 0.1A-6.0A)
- Discharge Current (Port 1: 0.1A-5.0A 10Watts max Port 2: 0.1A-2.0A 5Watts max)
- Discharge Voltage
-- LiPo 3.0V - 3.3V
-- LiIon 2.9V - 3.2V
-- LiFe 2.6V - 2.9V
-- NiMH 0.1V - 1.1V
-- NiCD 0.1V - 1.1V
- Terminal Voltage Control
-- LiPo 4.18V - 4.30V
-- LiIon 4.08V - 4.20V
-- LiFe 3.58V - 3.70V
About The Product
1. AC Input voltage AC 100V-240V (Auto Switching Power Supply)
2. DC Input voltage DC 11.0V-18.0V (DC Power Cable not included)
3. Charge current Port 1: 0.1A-10.0A Port 1: 0.1A-6.0A
5. Discharge current Port 1: 0.1A-5.0A Port 2: 0.1A-2.0A
6. Charge power max Total: 100Watts Port 1: 100Watts* Port 2: 50Watts
7. Discharge power maxPort 1: 10Watts Port 2: 5Watts
8. Balance current max. 300mA/cell
9. Lithium battery cell count 1-6 (S)eries
11. NiCd/NiMH battery cell count 1-15 Cells
12. Lithium battery types Li-Po Li-ion Li-Fe
13. Pb battery voltage 2V-20V (1-10 cells)
14. Capacity: 100mAh - 50000mAh
15. Temperature cut-off (20 degree C-80 degree C 68 degree F-1765 degree F)
16. NiMH & NiCD trickle (OFF or 50mA - 300mA)
17. NiMH & NiCD peak delay (OFF or 1min - 5min)
18. NiMH & NiCD delta Peak sensitivity (3mV/C - 14mV/C)
19. Save program system settings
20. Rest time between charge/discharge cycles (1min - 60min)
21. Safety Timer (Off or 1min - 72
---------------------------------------
