Description
The USB 2.0 Graphic Adapter allows you to connect an extra monitor to your desktop PC or laptop's USB port. The connected monitor can be configured to either clone your primary screen, or extend the Windows desktop allowing visibility of more applications at the same time.
The USB 2.0 Graphic Adapter driver used to control the extra screen uses very little computer resource and offers a vast array of screen resolutions and color depths. This ensures that there is little difference in performance between a directly connected screen and a screen connected through the USB 2.0 Graphic Adapter
The USB 2.0 Graphic Adapter supports up to six simultaneous displays, including widescreen displays, extending your desktop and your horizons. It operates at a high resolution of 1600x1200/1680x1050/1920x1080.
Entertainment:
•View videos/TV on one screen and your desktop on the other screen
•Easily connect additional monitors using a USB 2.0 Cable
•Enjoy resolutions of up to 1600x1200 at 32 bit color
•Allows for effortless multitasking
•Bus Powered - No external power supply needed
•Supports usage through powered KVMP's or USB hubs
Features
Display Modes:
Can easily Mirror the main display
Extend left, right, above, or below
Can be rotated left, right, or upside-down
DVI , VGA and HDMI Support
Maximum: 1600x1200 or 1920x1080 Digital (@60Hz 32-bit)
USB 2.0 Powered - Ultra Low Power
Lossless Compression
CRT, LCD, Projector Displays
Windows Vista Aero Support
Windows XP and Vista 32bit Support
Standard and Widescreen ratio aspects
High-Performance DDR Memory
Uses a virtual driver
Stackable by design with a small footprint
Completely silent operation
Onboard power and status indicator LEDs
Portable, making it easy for travel
Model WS-UG17D1
Name VIEWPLEX 165
USB Specification 2.0 Compliant
Video Resolution Max Pixels 1600x1200/1920x1080
Video Output DVI/VGA/HDMI(Optional)
Ports 1 Female DVI / 1 USB mini-B
Power Consumption 5V
Support Function 1.Primary 2.Extended 3.Mirror
Link up to Six simultaneous displays
Dimensions 90mm L x 43mm W x 16mm H
Package Content
1 x USB to DVI Adapter
1 x Quick Start Guide
1 x CD-ROM with User Guide and Installation Software
1 x USB 2.0 Cable
1 x DVI to VGA Adapter
1 x DVI to HDMI Adapter (Optional)
Requirements
Available USB 2.0 Port
Operating System:
Windows 2000 SP4
Windows XP SP2
Windows Vista 32/64Bit with Aero support
Windows 7 32/64Bit
Items will be securely boxed when shipped
