Specifications
Model CS-C8W-A0-1H3WKFL
Camera
Image Sensor 1/2.7" Progressive Scan CMOS
Shutter Speed Self-Adaptive shutter
Lens 4mm@ F1.6, viewing angle:87`b0 (Horizontal),105`b0(Diagonal) 6mm@ F1.6, viewing angle:55`b0 (Horizontal), 66`b0(Diagonal)
PT Angle Pan: 340`b0, Tilt: 80`b0
Minimum Illumination 0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories)
Lens Mount M12
Day & Night IR-Cut lter with auto-switching
DNR 3D DNR
WDR Digital WDR
Night Vision Distance Up to 98 ft / 30 m
Video & Audio
Max. Resolution 2K
Frame Rate Max: 30fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
H.265 Type Main Prole
Video Bit Rate Quad HD; Full HD; Hi-Def; Standard. Adaptive bit rate
Audio Bit Rate Self-Adaptive
Max. Bitrate 2 Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security WPA-PSK / WPA2-PSK
Transmission Rate 11b: 11 Mbps,11g: 54 Mbps,11n: 72 Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Wired Network RJ45 `d7 1 (10M / 100M Adaptive Ethernet Port)
Storage
Local Storage Supports microSD card (Up to 256 GB)
Cloud Storage Supports EZVIZ CloudPlay storage (Subscription required)
Function
Smart Alarm AI-Powered Human / Vehicle Shape Detection
Auto Tracking Supports
Customized Alert Area Supports
Two-Way Talk Supports
General Function Anti-Flicker, Dual-Stream, Heart Beat,Password Protection, Watermark
General
Operating Conditions -30 `b0C to 60 `b0C (-22 `b0F to 140 `b0F), humidity 95% or less (non-condensing)
IP Grade Weatherproof Design
Power Supply DC 12V / 1A
Power Consumption MAX. 6W
Dimensions 112 `d7 171 `d7 156 mm (4.41`d7 6.73 `d7 6.15 inch)
Packaging Dimensions 187 `d7 174 `d7 186 mm (7.36 `d7 6.85 `d77.34 inch)
Weight Product: 605 g (21.34 oz) With package: 992 g (34.99 oz)
