Features:
1.3 megapixel high resolution
HD video output
Low illumination
IP66 rating
IR range: up to 30m
True day / night
Specification:
Camera
Image Sensor: 1/3" Progressive Scan CMOS
Min. Illumination: 0.01 lux @ F1.2, AGC ON
0 lux with IR
Shutter time: 1/25(1/30)s ~ 1/100,000s
Lens: 6mm @ F2.0, angle of view: 45.3`b0(4mm, 8mm optional)
Lens Mount: M12
Day& Night: IR cut filter with auto switch
Compression Standard
Video Compression: H.264 / MPEG4 / MJPEG
Bit Rate: 32 Kbps ~ 16 Mbps
Max. Image Resolution: 1280x960
Frame Rate: 50Hz: 25fps (1280 `d7 960), 25fps (1280 `d7 720)
60Hz: 30fps (1280 `d7 960), 30fps (1280 `d7 720)
Image Settings: Saturation, brightness, contrast adjustable through client software or web browser
Network
Network Storage: NAS (iSCSI optional)
Alarm Trigger: Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception
Protocols: TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour(SIP optional)
Security: User authentication, watermark
System Compatibility: ONVIF, PSIA, CGI
Interface
Communication Interface: 1 RJ45 10M / 100M ethernet interface
General
Operating Conditions: -10 `b0C ~ 60 `b0C (14 `b0F ~ 140 `b0F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC `b1 10%, PoE (802.3af)
Power Consumption: Max. 6.5W
Weather Proof: IP66
IR Range: -I: Approx 20 to 30 meters(65.6-98.4ft)
Dimensions: 85.5 `d7 83 `d7 165 mm
Weight: 1000g
