VAG COM KKL 409.1 OBD-II USB Diagnostic scanner cable for VW/ Audi - LOCAL STOCK

This diagnostic cable is usable for ISO9141 and KWP2000 transmission protocol like used for example by: Audi,Skoda,Seat,Volkswagen

DTC Memory - read and clear manufacturer diagnostic trouble codes
Actual Values - access live data
Activation - selected components can be activated Code Module - code new control modules (most models through 2002)
Adaptation - read/reset Service Light parameters, view/change block learn values
Basic Settings - view and change control module default settings (Excluding 1.8T 01 and newer)
Individual Values - read individual measuring values Readiness Code - Check status of applicable emissions related systems
Remote Control Programming - program Radio Frequency keys
Key Matching - match keys to Immobilizer control module (5 digit)

Reference Data
1.This cable can not work if your car uses a protocol/bussystem like VPW, PWM or CAN-bus.
2. Terminal K = Bus of communication
3. Terminal L = Ignition for waking up car computing system (ECU: Engine Control Unit)
4. Existed 3 different protocols with same OBD2 connector incl. ISO/KWP, VPW, PMW
5. This K/L Diagnostic interface & cables work on ISO/KWP (Key Word Protocol) launched after 1996 only.
6. Supported also ISO9141 protocol
7. V.A.G-COM shareware download:  http://www.ross-tech.com/vcds-lite/download/index.php
Read & erase error code, log data e.g., speed, gasoline-consume, engine-rotating (RPM: Rotation Per Minutes).

Package Includes:

• One USB KKL Cable

• One CD with driver software

Vehicle Coverage:

Most Volkswagen Audi Group cars: 1990 - 2004

FAQ

Does the cable come with drivers and software? It comes with drivers and you would need to download the software from Ross tech's website, called VCDS lite

Is it compatible with my car? I suggest having a look at Rosstech's website for the compatibility chart, to ensure your car will be compatible.

What diagnostics can be done? Please have a look at the features section of the VCDS lite product page on Rosstech's website.
