Monitor and control your MultiPlus and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your MultiPlus to setting a Geofence for-hire vehicles and more.
Two AC OutputsThe main output has no-break functionality. The MultiPlus takes over the supply to the connected loads in the event of agrid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computersand other electronic equipment will continue to operate without disruption.The second output is life only when AC is available on the input of the MultiPlus. Loads that should not discharge thebattery, like a water heater, for example, can be connected to this output (second output available on models rated at 3 kVAand more).
Virtually unlimited power thanks to parallel operationUp to 6 Multis can operate in parallel to achieve higher power output. Six 24/5000/120 units, for example, will provide 25 kW / 30 kVA output power with 720 Amps charging capacity.
Three-phase capabilityIn addition to parallel connection, three units of the same model can be configured for three-phase output. But that's not all: up to 6 sets of three units can be parallel connected for a 75 kW / 90 kVA inverter and more than 2000 Amps charging capacity.
PowerControl - Dealing with limited generator, shore side or grid powerThe MultiPlus is a very powerful battery charger. It will, therefore, draw a lot of current from the generator or shore side supply (nearly 10 A per 5 kVA Multi at 230 VAC). With the Multi Control Panel, a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.
PowerAssist - Boosting the capacity of shore or generator powerThis feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.
Solar energy: AC power available even during a grid failureThe MultiPlus can be used in off-grid as well as grid-connected PV and other alternative energy systems.Loss of mains detection software is available.
System configuring- In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure.
- Parallel and three-phase applications can be configured with VE. Bus Quick Configure and VE.Bus SystemConfigurator software.
- Off-grid, grid-interactive and self-consumption applications, involving grid-tie inverters and/or MPPT Solar Chargers can be configured with Assistants (dedicated software for specific applications).
On-site Monitoring and controlSeveral options are available: Battery Monitor, Multi Control Panel, Color Control GX, or other GX devices, smartphone or tablet (Bluetooth Smart), laptop, or computer (USB or RS232).
Remote Monitoring and controlColor Control GX or other GX devices.Data can be stored and displayed on our VRM (Victron Remote Management) website, free of charge.
Remote configuringWhen connected to the Ethernet, systems with a Color Control GX or other GX device can be accessed and settings can be changed remotely.
