Vishay (BFC233820103) Safety Capacitor, Metallized PP, 0.01 µF, ± 20%

Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 0.01 µF, ± 20%, X2, ThroughHoleProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: Radial Box - 2 PinCapacitance: 10000pFCapacitance Tolerance: ± 20%Suppression Class: X2Voltage Rating Y: -Capacitor Mounting: Through HoleVoltage Rating X: 310VACdv/dt Rating: 600V/µsHumidity Rating: GRADE II (Test Condition A)Lead Spacing: 7.5mmOperating Temperature Min: -55°COperating Temperature Range: -55°C to +105°COperating Temperature Max: 105°CProduct Range: MKP3382Series Name: MKP3382Automotive Qualification Standard: -Product OverviewThe Vishay MKP3382 X2 series are radial leaded, interference suppression filmcapacitors. The capacitance range includes E12 decade values from 0.001µF to3.3µF. These film capacitors are non polarized electrical capacitors with aninsulated Polypropylene film as dielectric.7.5mm to 27.5mm lead pitch±20%, ±10% and ±5% toleranceRated AC voltage of 310VRated DC voltage of 800V at 85°C and 630V at 110°CMeets IEC 60384-14-3, EN60384-14, IEC 60065, UL 60384-14, CSA-E384-14, CQCstandardsFlame retardant plastic case and epoxy resin coated with tinned wire
