Features
- Internet Sharing with built in 4 Port Fast Ethernet Switch. Integrated Wi-Fi access point
- Supports FDD LTE, 3G and 2G mobile broadband network access in one device
- IEEE 802.11 b/g/n compliant WLAN
- Advanced Firewall to protect the network
Description
- The fixed router operates with multiple frequency band operation in FDD LTE with support for HSPA , HSPA, EDGE and GPRS
- FDD-LTE
- Frequency Band : 800 MHz (Band 20), 1800 MHz (Band 3) or 2.5 GHz (Band 7)
- Transfer Speed : Downlink : 100 Mbit/s, Uplink : 50 Mbit/s
- DC-HSPA
- Frequency Band : 2100 MHz (Band 1) and 900 MHz (Band 8)
- Transfer Speed : Downlink : 42 Mbit/s, Uplink : 5.76 Mbit/s
- EDGE / GPRS /GSM
- Frequency Band : Quadband 850/900/1800/1900 MHz
- Transfer Speed : Downlink : 236.8 Kbits, Uplink : 236.8 Kbits
802 b/g/n WLAN access point
- Allows 10 Wi-Fi enabled devices to simultaneously connect to the internet
- Operates at 2.4 GHz
Router and Network Security Features
- Supports advanced IP networking features including NAT, VPN pass-through, port filtering, port forwarding and DHCP to safely access the network.
- Wi-Fi Authentication : WAP, WPA, WPA2, WPS
- GPRS Authentication : PAP/CHAP
Integrated 4 10/100 Fast Ethernet Switch
All ethernet ports supports auto crossover (MDI, MDI-X) so there’s no need for crossover cables.
LED Status
- System status
- LTE/3G status
- Charging status
Broadband Wireless Specification Technology and Bands • LTE :3GPP Rel. 8/9 FDD
- Bands 3,8,20 – 10/20 MHz Channels
• WCDMA :3GPP Rel. 8/9 DC-HSPA , Rel. 7 HSPA , Rel. 6 HSUPA, Rel. 5 HSDPA, Rel. ’99 WCDMA
- Bands 900/2100 MHz
• GPRS/EDGE :3GPP Rel. ’99 WCDMA Band 850/900/1800/1900 MHz
• WiFi – 802.11 b/g/n (1 TX / 1RX) at 2.4 GHz Data Speeds • LTE Mode : 100 Mbit/s downlink, 50 Mbit/s uplink
• HSPA /HSPA Mode : 42.2 Mbit/s downlink, 5.76 Mbit/s uplink
• EDGE Mode : 236.8 Kbit/s downlink, 236.8 kbit/s uplink LTE Channel Bandwidth • Upto 20 MHz MIMO • 1 Transmit with 2 Receive
• MIMO 2×2 with receive diversity at downlink Antenna Type • Two 2dBi external antenna Wireless Lan Specification Standard • 802.11 b/g/n (2TX and 2RX) Frequency Range • 2.4 GHz – 2.4835 GHz Channels • 1 – 11 (America), 1 – 13 (Europe), 1 – 14 (Japan) Security • 64/128 Bit WEP, WPA – PSK, WPA2- PSK, WPS with Hardware Button Antenna Type • Two Internal Antenna Wired Lan Specification Standard • IEEE 802.3 , 802.3 u Interface Type • Four 10/100 Mbit/s Ethernet port with autosensing technology System Specification Network Protocols • TCP, UDP, ARP, ICMP and IGMP
• DHCP Client/Server
• DNS Proxy Relay/Dynamic DNS
• SNTP Firewall and NAT • NAT and Stateful Packet Inspection (SPI)
• Port Forwarding/Port Filtering
• DMZ
• MAC Filtering VPN Passthrough • PPTP
• L2TP
• IPSec Device Management • Web Based
• DHCP Server and Client
• Firmware Upgrade through Web Browser Ports • LAN : Four 10/100 Fast Ethernet RJ45 Ports
• USIM Socket
• One Reset Button
• One Power On/Off Switch
• One WPS Button Status Display • LED Display : Lights to indicate status Environmental Condition • Operating Temperature : 00 C ~ 400 C
• Storage Temperature : – 100 C ~ 650 C Dimension • Length x Width x Height (L x W x H) : 209 x 58.5 x 126mm Battery and Power Supply • Input : 100 – 230 V AC, 50/60 Hz
• Output : 12V, 1.5A
