The VSOL V1600GS-F Single Port GPON OLT is a high-performance, cost-effective optical line terminal purpose-built for delivering ultra-fast and reliable fiber optic connectivity across small to medium-sized networks. Designed in a compact 1U box form factor, the V1600GS-F integrates GPON OLT functionality with gateway and AC controller features, making it an all-in-one solution for FTTH (Fiber-to-the-Home), SOHO environments, SMBs, and rental housing network upgrades.
Equipped with one GPON port and supporting a splitting ratio of up to 1_128, this device can handle large-scale user deployments while maintaining excellent performance. With transmission distances of up to 20km, the V1600GS-F ensures stable and long-range coverage, perfect for delivering gigabit broadband services over passive optical networks.
Capable of 1.25Gbps upstream and 2.5Gbps downstream, the V1600GS-F is ideal for applications that demand high throughput such as HD video streaming, IP telephony, cloud access, and enterprise-level data management. Its flexible deployment makes it suitable for both urban and rural network topologies where performance and affordability are critical.
The device features three uplink ports two Gigabit Ethernet RJ45 and one SFP/SFP+ combo port supporting up to 10Gbps ensuring fast and scalable backhaul connectivity. It includes centralized network management through WEB, Telnet, CLI, and SNMP, offering streamlined deployment and simplified administration across a range of network architectures. With support for plug-and-play AP control and centralized AC management, it forms the backbone of a POL (Passive Optical LAN) setup for modern offices and enterprise parks.
Additionally, the V1600GS-F is engineered for resilience and durability, featuring 4KV lightning protection for power and 1KV surge protection on device interfaces. It also supports both AC (100~240V) and DC (12V/2A) power inputs, offering flexibility across installation scenarios.
FEATURES:
- All-in-one Single Port GPON OLT
- Integrated OLT, Gateway and AC Function
- High-Speed Fiber Optic Coverage
- Easy Installation Saves Investment
- Centralized Management and Plug & Play
- AC+AP Solution
- POL Network of Small & Medium-sized Enterprises
- Rental Housing Network Renovation
SPECIFICATIONS:
- Rack: 1U
- Uplink Port
- QTY: 3
- RJ45(GE): 2
- SFP(GE)/SFP+(10GE): 1
- GPON Port Specification
- QTY: 1
- Fiber Type_ 9/125m SM
- Connector: SC/UPC, TX_ 7.5±0.5dBm, Sen_ -32dBm
- GPON port speed_ Upstream 1.244Gbps | Downstream 2.488Gbps
- Wavelength: TX 1490nm, RX 1310nm
- Max splitting ratio_ 1_128
- Transmission Distance_ 20KM
- Management Ports_ 1 x USB-COM(Type-C) port
- Backplane Bandwidth_ 16Gbps
- Port Forwarding Rate_ 23.808Mpps
- Management Mode_ WEB/Telnet/CLI/SNMP
- Power Supply
- AC Power Adapter_ Working Voltage Range_ 100~240V | Rated Voltage_ 110V/220V
- DC Power Adapter_ DC 12V/2A
- Lightning Protection Level
- Power supply_ 4KV
- Device Interface_ 1KV
- Product Dimensions_ 21 x 17.3 x 4.36 cm
- Product Weight_ 1070 g
WHAT'S IN THE BOX_
- VSOL V1600GS-F Single Port GPON Optical Line Terminal x1
Lenght: 34.5
Width: 7
Height: 26.5
Colour: Aluminium Grey
Warranty: 12 Months
